Sony Crystal LED Video Wall Display Cabinets - ZRD-B12A and ZRD-B15A
The Sony ZRD-B12A and ZRD-B15A Crystal LED video wall modular display cabinets redefine visual excellence with cutting-edge technology tailored for high-impact indoor applications. Designed to deliver immersive viewing experiences, these displays boast stunning brightness levels, exceptional color accuracy, and an ultra-wide viewing angle, making them ideal for corporate, entertainment, and retail environments.
Engineered for performance and reliability, these modular display cabinets feature an anti-reflection coating and robust build quality, ensuring superior visuals under diverse lighting conditions. With a contrast ratio exceeding 1,000,000:1 and precise color gamut reproduction, they provide unmatched image clarity, perfect for showcasing intricate details and vibrant hues. Whether you're viewing at 120 frames per second or under varying ambient light, the displays maintain exceptional consistency and quality.
Both models include innovative internal processing capabilities, enabling seamless integration and enhanced flexibility. Whether your priority is the finer pixel pitch of the ZRD-B12A or the slightly larger pitch of the ZRD-B15A, Sony's Crystal LED video walls promise to elevate any space with stunning visuals and reliable performance. Optimize your indoor display solutions with these state-of-the-art modular cabinets.
Key Features
- High brightness for vivid, lifelike visuals: 1,800 cd/m2 (ZRD-B12A) and 1,700 cd/m2 (ZRD-B15A).
- Anti-reflection coating for optimal image clarity in various lighting environments.
- Ultra-wide 170° horizontal and vertical viewing angles for consistent viewing from any position.
- Exceptional color accuracy covering up to 97% of DCI-P3 gamut and 143% of sRGB.
- Advanced 22-bit internal processing for seamless image quality.
- Compact and modular design for flexible installation in diverse spaces.
Technical Specifications
Shared Features
Surface: Anti-reflection coating
Contrast Ratio (0 lx): More than 1,000,000:1
Viewing Angle (H/V): 170° / 170°
Color Gamut: Approx. 83% (BT2020), 97% (DCI-P3), 143% (sRGB)
Bit Depth: 22-bit Internal Processing
Frame Rate: Up to 120 fps
Signal Interface: 1 in 1 out (2 x RJ45)
Operating Temperature / Humidity: 32°F to 104°F / 20% to 80% (no condensation)
Storage Temperature / Humidity: -4°F to 140°F / 20% to 80% (no condensation)
Power Requirements: AC 100-240 V, 50/60 Hz
Dimensions (W x H x D): 23.94" x 13.46" x 2.99"
Mass: Approx. 20 lb 15.10 oz (Per-sqm: Approx. 45.7 lb)
Application: Indoor
ZRD-B12A
Pixel Pitch: 0.05 in (1.26 mm)
Resolution (W x H): 480 x 270
Brightness (max.): 1,800 cd/m2
Power Consumption (max.): 157 W (Per-sqm: 755 W)
Power Consumption (ave.): 64 W (Per-sqm: 308 W)
ZRD-B15A
Pixel Pitch: 0.06 in (1.58 mm)
Resolution (W x H): 384 x 216
Brightness (max.): 1,700 cd/m2
Power Consumption (max.): 150 W (Per-sqm: 721 W)
Power Consumption (ave.): 58 W (Per-sqm: 279 W)
What’s Included
- ZRD-B12A or ZRD-B15A LED display cabinet
- Installation manual
- Power supply cables
- Signal interface accessories
