SoundTube CI150 5.25-Inch 2-Way In-Wall LCR Speaker
The CI150 combines left, right, and center front-channel performance into just two in-wall enclosures using patented triple 5.25" tri-laminate Kevlar/RPF™/glass-fiber flat-piston woofers and dual 1" user-adjustable variable-axis soft-dome tweeters to create a seamless, wide soundstage without the need for a separate center speaker.
Featuring an extruded-aluminum Positive Clamping™ mounting system, the CI150 installs flush for a discreet, furniture-grade finish. Its infinite-baffle sealed enclosure and paintable steel grille integrate into any décor, while the low-profile design pairs perfectly with Premier Collection PC1.5 and PC33.5 speakers.
Key Features
- Woofers: (3) 5.25" RPF® flat-piston fiberglass & Kevlar composite cones with NBR surrounds
- Tweeters: (2) 1" variable-axis soft domes with Unicell™ Acoustic Treatment
- Mounting: Patented extruded-aluminum Positive Clamping™ system
- Enclosure: Infinite-baffle sealed in-wall design
- Inputs: Terminal strip
- Cutout: 7 in (177.8 mm) Ø × 3.87 in (98.4 mm) depth
- Frequency Response: 55 Hz–22 kHz (±3 dB)
- Max SPL @ 1 m: 114 dB
- Impedance: 4 Ω nominal
- Recommended Power: 15–200 W
- Sensitivity: 90 dB @ 2.83 V/1 m
- Grille: Standard-flange, friction-fit, galvanized, powder-coated steel – white, paintable
Technical Specifications
- Color: White
- UPC: 644216205301
- Enclosure Properties: Sealed, infinite-baffle
- Cutout Dimensions: 7" Ø × 3.87" depth
- Frequency Response: 55 Hz–22 kHz (±3 dB)
- Max SPL @ 1 m: 114 dB
- Nominal Impedance: 4 Ω
- Recommended Power: 15–200 W
- Sensitivity: 90 dB @ 2.83 V/1 m
- Source Inputs: Terminal strip
- Optional Accessories: Rough-In Bracket (RB19)
What's Included
- Grille
- Hole Template
- Mounting Assembly
