SoundTube IW500B‑WH 5.25-Inch In‑Wall Coaxial Speaker, White

SoundTube | SKU: SOUNT-IW500BWH
1 5
$38700

Free Shipping

Estimated Shipping Widget will be displayed here!

Enjoy free standard shipping on all orders over $99. Please note that this offer excludes oversized, overweight, special orders, custom products, and items with minimal profitability. Most orders placed before 10:00am PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible. Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand. No restocking fee will be charged when you opt for store credit. Exclusions apply.

Condition: New

SoundTube IW500B‑WH 5.25-Inch In‑Wall Coaxial Speaker, White

The IW500B‑WH is a transformer‑tappable, in‑wall coaxial speaker featuring a 5.25″ polypropylene woofer and 1″ convex titanium tweeter with FerroFluid cooling. It is designed for distributed (25/70.7/100 V) or 8 Ω applications, utilizing SoundTube’s BroadBeam® waveguide for wide and consistent dispersion.

Featuring a sealed infinite‑baffle design with an integrated UL‑listed steel backcan, the speaker offers transformative flexibility via its six‑position rotary tap switch, including direct bypass. The low‑profile grille and constant‑tension mounting system enable fast installation and aesthetic integration.

Key Features

  • Driver Configuration: 5.25″ polypropylene woofer with butyl surround; 1″ convex titanium tweeter on BroadBeam® waveguide
  • Power Handling: 75 W RMS / 150 W program
  • Sensitivity: 88 dB @ 1 W/1 m
  • Frequency Range: 69 Hz – 22 kHz (−10 dB); 71 Hz – 22 kHz (−3 dB)
  • Dispersion: ~115° avg (2–10 kHz); 90° × 100° @ 2 kHz; 70° × 85° @ 10 kHz
  • Transformer Options: Six-position rotary taps: 0.63 W–33 W for 25 V; up to 33 W for 70.7 V/100 V; plus 8 Ω direct bypass
  • Construction: ABS infinite‑baffle with integrated steel backcan; powder‑coated steel grille
  • Installation: Constant‑tension blind‑mount system; paint mask and hole template included

Technical Specifications

  • Dimensions: 11.84″ H × 8.64″ Ø × 3.9″ Depth (300.7 × 219.5 × 99.1 mm)
  • Weight: 8.9 lb (4.0 kg)
  • Nominal Impedance: 8 Ω
  • Crossover Frequency: 3.0 kHz, 12 dB/octave
  • Directivity Factor (Q): ~4.2 averaged (100 Hz–10 kHz), ~4.9 actual avg
  • Directivity Index (DI): ~5.6 dB averaged; ~6.0 dB avg
  • Transformer Taps Max Setting: 5 W @ 25 V; 33 W max @ 70.7 V and 100 V
  • Sensitivity: 88 dB @ 1 W/1 m and 2.83 V/1 m

What’s Included

  • IW500B‑WH in‑wall speaker unit (White)
  • Powder‑coated steel grille (White)
  • Mounting hardware, paint mask, hole template
  • 1/2″ conduit connector and wire nuts
