Theatrixx Dual Channel 12G-SDI to Fiber Converter, Single-Mode or Multimode, OpticalCON Duo or Optical QUAD

The Theatrixx 2SDI2FIBER-12G is a robust dual 12G-SDI to dual fiber converter that enables high-quality video signal transmission over fiber optics. It supports a variety of video formats including 12G, 6G, 3G-SDI, HD-SDI, and SD-SDI, making it versatile for different broadcasting needs. The device is built with a durable design, ensuring reliable performance in various environments, and features a built-in power supply for easy integration into existing setups.

This converter is ideal for professional video applications, providing a choice between multimode and singlemode fiber connections. It adheres to multiple SMPTE standards, ensuring compatibility with a wide range of video equipment. The compact form factor and lightweight design make it easy to transport and install, while the loop-thru functionality allows for seamless integration into existing SDI workflows.

Key Features:

• Video Input: 2 x 12G/6G/3G/HD/SD SDI BNC
• Loop-thru: 2 x 12G/6G/3G/HD/SD SDI BNC
• Supported Signals: 12G/6G/3G-SDI Level A and B, HD-SDI, SD-SDI with embedded audio
• SMPTE Standards: 2082-1, 2082-10, 425 M Level A & B, 424 M, 292 M, 259 M
• Dimensions: 62 mm (H) x 180 mm (D) x 221 mm (W)
• Weight: 2 kg (4.4 lbs)
• Operating Temperature: 0-40 °C
• Power Consumption: 45W max.
• Operational Voltage Range: 100-240V, 50-60Hz

Technical Specifications

• Measuring System: Metric
• Height: 62 mm
• Depth: 180 mm
• Width: 221 mm
• Weight: 2 kg
• Relative Humidity: 0% to 90% non-condensing
• Power Supply: Built-in power supply, PowerCon True1 input/output
• Courtesy Outlet: Max 10 A, same voltage as input

What's in the Box

• xVision Converter Dual 12G-SDI to Dual Fiber
• AC Mains to PowerCON True1 cable (1.5m, specify plug type at ordering)
