Theatrixx Reversible Module 3G-SDI to Fiber Converter, Single-Mode or Multimode, Optical SDI on ST, OpticalCON DUO or OpticalCON QUAD

The Theatrixx RM-SDI2FIBER is a high-performance SDI to fiber converter designed for professional video applications. It supports a wide range of video formats including 3G-SDI, HD-SDI, and SD-SDI, ensuring compatibility with various broadcasting standards. The unit features both multimode and singlemode optical outputs, providing flexibility in connectivity options. Its compact design allows for easy integration into existing setups, making it an ideal choice for live events, studios, and broadcast environments.

With a robust build quality and a range of supported SMPTE standards, the RM-SDI2FIBER ensures reliable performance in demanding conditions. The converter is also available as a standalone unit, catering to different user needs. Its reversible redundant power supply enhances reliability, making it a dependable choice for critical applications.

Key Features:

• Video Input: 1 x 3G/HD/SD SDI BNC
• Loop-thru: 1 x 3G/HD/SD SDI BNC
• Video Output: Choice of Multimode or Singlemode, Optical SDI on ST, OpticalCON DUO or OpticalCON QUAD
• Supported Signals: 3G-SDI Level A and B, HD-SDI, SD-SDI with embedded audio
• SMPTE Standards: 425 M Level A & B, 424 M, 292 M, 259 M

Technical Specifications

• Height: 121.5 mm (4.78 in)
• Depth: 225 mm (8.85 in)
• Width: 41 mm (1.61 in)
• Weight: 710 g (1.56 lbs)
• Relative Humidity: 0% to 90% non-condensing
• Operating Temperature: 0-40 °C
• Power Supply: Reversible redundant power fed by XVVRF8 (8-Bay Rackmount Frame)
• Power Consumption: 20W
• Voltage Range: 12VDC

What's in the Box

• Theatrixx Reversible Module SDI to Fiber
