Traynor YCV20WR 1 x 12 Inch 15 Watt All-Tube Guitar Amp, Celestion Greenback

Traynor YCV20WR 1 x 12 Inch 15 Watt All-Tube Guitar Amp, Celestion Greenback

The Traynor Custom Valve 20WR answers the need for guitar players looking for superior sounding all-tube tone in a smaller, yet still feature loaded, lower-powered amplifier. The Traynor Custom Valve 20WR is perfect for the studio or for any gig where 15 tube watts is more than enough power, but full functionality is required. Unlike competitive amplifiers in this class, the YCV20WR offers the discriminating player two discrete footswitchable channels with true independent gain and volume controls on each channel. A master three band EQ, effects loop, as well as an internal spring reverb are all standard equipment. Additional controls include bright switch on the clean channel and boost switch on the lead channel. The Traynor Custom Valve 20WR is perfect for the studio or for any gig where 15 tube watts is more than enough power, but full functionality is required. Unlike competitive amplifiers in this class, the YCV20WR offers the discriminating player two discrete footswitchable channels with true independent gain and volume controls on each channel. A master three band EQ, effects loop, as well as an internal spring reverb are all standard equipment. Additional controls include bright switch on the clean channel and boost switch on the lead channel.

Key Features

• Class “A” Cathode bias amplifier
• Fully regulated power supply with tube rectifier emulation
• Classic Celestion G12M “Greenback” speaker
• Speaker jack and selectable defeat for disabling the internal speaker
• All plywood enclosure
• Custom design “Chicken Beak” knobs
• DC filaments on preamp tubes eliminate hum
• Long spring reverb
• Wine Red leatherette finsh with oatmeal grille
• D.I. Output for connections straight to the board

Technical Specifications

Cabinet Impedance (Ohms)
8
Power @ min. impedance (Watts)
15
Speaker Configuration - LF (Size / Power)
Single 12 inch Celestion Greenback
Inputs
2
Channel 1 - Inputs
1/4 inch phono
Channel 1 - Controls
Gain, Volume
Channel 1 - Switches
Boost
Channel 2 - Inputs
Shares Channel 1
Channel 2 - Controls
Gain, Volume
Channel 2 - Switches
Channel Select, Brightness
Main Tone Controls
Bass, Mid, Treble
Line Out (type / configuration)
1/4 inch TRS / Rear
Effects Loop / Location
Yes / Rear
Effects Footswitch / Function
Yes / Channel Select / Boost
Internal Reverb / Effects
Spring Reverb
LED Indicators
Channel / Boost / Power / Standby
External speaker output / location
Yes / Rear with intenral speaker defeat
Headphone Jack
Yes
Dimensions (DWH, inches)
9.5 x 18 x 17
Dimensions (DWH, cm)
24 x 47 x 43
Weight (lbs / kg)
37.9 / 17.2
