Ubiquiti airMAX PowerBeam M5 400 Bridge
The Ubiquiti airMAX PowerBeam M5 400 Bridge offers a high-performance solution for creating long-range wireless connections. Featuring a 25 dBi antenna and a rugged UV-stabilized plastic enclosure, this device is built for durability in harsh outdoor conditions. Its advanced design ensures reliable and efficient connectivity over distances up to 25 km (15.5 miles), making it ideal for point-to-point wireless links, such as rural internet deployments or connecting remote locations.
With easy installation and passive PoE for power, the PowerBeam M5 400 ensures seamless integration into your network. The bridge is capable of maintaining high throughput of up to 150 Mbps, and it’s equipped with a Gigabit Ethernet port to deliver optimal performance. Whether for commercial or personal use, the PowerBeam M5 400 is the ideal choice for outdoor wireless networking.
Key Features
- 25 dBi antenna for long-range performance
- Up to 150 Mbps throughput
- Passive PoE support for easy installation
- Durable, weather-resistant design
- Up to 25 km (15.5 miles) range
Technical Specifications
Dimensions: 420 x 420 x 275 mm (16.5 x 16.5 x 10.8")
Weight: 1.8 kg (4.8 lb)
Enclosure Material: UV-stabilized plastic
Mounting: Pole mount kit (Included)
Wind Survivability: 200 km/h (125 mph)
Wind Loading: 342.5 N @ 200 km/h (77 lbf @ 125 mph)
Networking Interface: (1) GbE RJ45 port
Power Method: Passive PoE 2-pair (Pairs 4, 5+; 7, 8 Return)
Power Supply: 24V, 0.5A gigabit PoE adapter (Included)
Supported Voltage Range: 20–27V DC
Max. Power Consumption: 8W
Max. TX Power: 26 dBm
Gain: 25 dBi
ESD/EMP Protection: Air/contact: ± 24 kV
LEDs: (1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs: Software-adjustable to custom RSSI levels
RoHS Compliance: Yes
Salt Fog Test: IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G method 509.5
Vibration Test: IEC 68-2-6
Temperature Shock Test: IEC 68-2-14
UV Test: IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test: ETS 300 019-1-4, Equivalent: MIL-STD-810 G method 506.5
Ambient Operating Temperature: -40 to 70° C (-40 to 158° F)
Ambient Operating Humidity: 5 to 95% noncondensing
Certifications: CE, FCC, IC
Gain: 22 dBi
Channel Sizes: 5/8/10/20/30/40 MHz
Polarization: Dual linear
Operating Frequency (MHz)
Worldwide: 5170 - 5875 MHz
US/CA: 5725 - 5850 MHz
