Ubiquiti UniFi U6 Mesh Access Point - High-Performance WiFi 6 Mesh
The Ubiquiti UniFi U6 Mesh is a high-performance WiFi 6 access point designed to provide seamless wireless coverage for both indoor and outdoor environments. With its advanced MU-MIMO and OFDMA technologies, this access point delivers superior connectivity for a large number of concurrent users, ensuring fast and reliable performance. Its compact, sleek design makes it easy to deploy in any location, while its weather-resistant enclosure ensures durability in outdoor installations. Perfect for high-density areas, the UniFi U6 Mesh offers extended range and exceptional speeds with WiFi 6 capabilities.
The U6 Mesh can be powered by PoE, simplifying installation and eliminating the need for additional power adapters. It integrates seamlessly with the UniFi Network Application, providing centralized control, monitoring, and configuration. This versatile access point ensures smooth and scalable network expansion, making it ideal for homes, offices, and large venues that require robust wireless performance.
Key Features:
- WiFi 6 technology with OFDMA and MU-MIMO for high efficiency
- Dual-band 2x2 MIMO and 4x4 MIMO technology
- Indoor and outdoor deployment with IPX5 weatherproofing
- Supports Power over Ethernet (PoE) for easy installation
- Seamless integration with the UniFi Network Application
- Extended coverage and high-speed connectivity for multiple users
Technical Specifications:
Mechanical
Dimensions: Ć48.5 x 159.5 mm (Ć1.9 x 6.3")
Weight: 400 g (14.1 oz)
Enclosure material: Polycarbonate, aluminum
Mount material: Polycarbonate
Weatherproofing: IPX5
Hardware
Networking interface: (1) GbE RJ45 port
Management interface: Ethernet, Bluetooth
Power method: PoE
Power supply: UniFi PoE switch, 48V, 0.32A PoE adapter (Included)
Supported voltage range: 44ā57V DC
Max. power consumption: 13W
Max. TX power:
Ā Ā Ā Ā 2.4 GHz: 22 dBm
Ā Ā Ā Ā 5 GHz: 26 dBm
MIMO:
Ā Ā Ā Ā 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
Ā Ā Ā Ā 5 GHz: 4 x 4 (DL/UL MU-MIMO)
Max. data rate:
Ā Ā Ā Ā 2.4 GHz: 573.5 Mbps (BW40)
Ā Ā Ā Ā 5 GHz: 4.8 Gbps (BW160)
Antenna gain:
Ā Ā Ā Ā 2.4 GHz: 3 dBi
Ā Ā Ā Ā 5 GHz: 5 dBi
LEDs: White/blue
Button: Factory reset
Mounting: Wall, desktop, pole (Included); Ceiling (Optional)
Ambient operating temperature: -30 to 60Ā° C (-22 to 140Ā° F)
Ambient operating humidity: 5 to 95% noncondensing
Certifications: CE, FCC, IC
Software
WiFi standards: 802.11a/b/g/n/ac/ax (WiFi 6)
Wireless security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID: 8 per radio
VLAN: 802.1Q
Advanced QoS: Per-user rate limiting
Guest traffic isolation: Supported
Concurrent clients: 300+
Zero wait DFS: Yes*
*Supported with upcoming firmware versions
Supported Data Rates
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac: 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
Application Requirements
UniFi Network: Version 6.2.51 and later
Package Contents:
- U6 Mesh Access Point
- Wall Mount Kit
- Pole Mount Kit
- Quick Start Guide
