Ubiquiti UniFi Instant 802.3af Gigabit PoE Adapter - GPON Network Device

The Ubiquiti UniFi Instant 802.3af Gigabit PoE Adapter is a compact and powerful device designed to extend your network over fiber optic GPON networks. This adapter seamlessly integrates with your GPON ONT (Optical Network Terminal) to deliver reliable high-speed connectivity to your Ubiquiti devices.

The UniFi Instant 802.3af Gigabit PoE Adapter supports Power over Ethernet (PoE) functionality, allowing you to power and connect your Ubiquiti devices through a single cable. This eliminates the need for separate power supplies at remote locations.

Key Features

• Extends network over GPON infrastructure
• Supports Power over Ethernet (PoE) for simplified installation
• Compact and lightweight design for easy integration
• Seamless integration with Ubiquiti UniFi Network application

Technical Specifications

Mechanical

• Dimensions: 69.5 x 13.7 x 11.3 mm (2.7 x 0.5 x 0.5")
• Weight: 30 g (1 oz)
• Enclosure materials: Zinc alloy, stainless steel

Hardware

• Networking interface:
  • (1) SC/APC, ITU-G.984 GPON WAN
  • (1) SGMI, Ethernet LAN
• Management interface: Ethernet In-Band
• Power method: SFP
• Supported voltage range: 3.3V
• Max. power consumption: 2W
• Total non-blocking line rate:
  • Downstream: 2.488 Gbps
  • Upstream: 1.244 Gbps
• Normal range of optical module:
  • TX: 0.5 to 5 dBm
  • RX: -8 to -28 dBm
• Ambient operating temperature: -10 to 45° C (14 to 113° F)
• Operating Humidity: 10 to 90% noncondensing
• Certifications: CE, FCC, IC

Fiber

• Operating wavelength:
  • TX: 1310 nm
  • RX: 1490 nm
• Line code: Scrambled NRZ
• Optical interface nominal bit rate:
  • Downstream: 2488.32 Mbit/s
  • Upstream: 1244.16 Mbit/s
• Physical reach: 20 km

Package Contents

• Ubiquiti UniFi Instant 802.3af Gigabit PoE Adapter
