Shure SLX4 Single Channel Diversity Receiver, L4 638-662 MHz (Used)

The Shure SLX4 Single Channel Diversity Receiver in the L4 638-662 MHz range stands as a testament to professional audio quality and user-friendly features. This used model is in great condition, exhibiting minimal signs of use. The SLX4 receiver simplifies the wireless setup process with its Automatic Frequency Selection and Automatic Transmitter Setup, ensuring seamless performance for any application where reliable audio transmission is critical. The device comes with rack hardware and detachable antennas for streamlined installation, making it ready to use right out of the box.

The SLX4 receiver is designed to accommodate the dynamic needs of modern audio environments with its wide bandwidth and multiple selectable frequencies. In addition, the model SLX4L variation includes logic outputs for advanced functionalities such as software echo cancellation and remote battery life monitoring. This makes it a versatile choice for a variety of professional setups, including live performances, conferences, and broadcast studios. Just remember to match frequency bands when purchasing separate wireless components to ensure optimal operation.

Key Features

• Automatic Frequency Selection
• Automatic Transmitter Setup
• 960 Selectable Frequencies Across a 24 MHz Bandwidth
• Detachable 1/4 Wave Antennas
• Microprocessor-Controlled Diversity
• RF Presence LED
• 5-Segment Audio Meter
• Multi-Function, Backlit LCD
• Low Battery Indicator
• Frequency and Power Lockout
• Rugged Metal Chassis
• Volume Control on Rear of Unit
• 1/2 Rack Design
• Furnished Rack Hardware
• Non-Slip Bumpers for Use Out of Rack
• XLR and 1/4 Inch Outputs

Specifications

• Dimensions: 42mm X 197mm X 134mm (H x W x D)
• Weight: 816 g (1 lb 13oz.)
• Housing: Galvanized Steel
• Sensitivity: -105 dBm for 12 dB SINAD, Typical
• Power Requirements: 12-18 V DC @ 150 mA, Supplied by External Power Supply (Tip Positive)
• Configuration: Impedance Balanced
• Maximum Audio Output Level Ref. ±38 kHz Deviation with 1 kHz Tone
• XLR Connector: -13 dBV (Into 600 Ohm Load)
• 6.35 mm (1/4 Inch) Connector: -2 dBV (Into 3 k Ohm Load)
• Impedance: XLR Connector: 200 Ohm, 6.35 mm (1/4 Inch) Connector: 1 k Ohm
• Pin Assignments: XLR Connector: 1=Ground, 2=Audio, 3=No Audio; 6.35 mm (1/4 Inch) Connector: Tip=Audio, Ring=No Audio, Sleeve=Ground
• Image Rejection: >70 dB, Typical
• Volume Adjustment Range: 0 dB to -25 dB

Package Contents

• Shure SLX4 Single Channel Diversity Receiver, L4 638-662 MHz
• Rack Hardware
• Detachable Antennas
• External Power Supply
• User Manual
