VigilLink 4-Port 4K HDMI KVM Switch

VigilLink VLKV-H2041 4-Port HDMI 2.0 Switcher

The VigilLink VLKV-H2041 4-Port HDMI 2.0 Switcher is an advanced AV solution designed to enhance your home theater or professional audio-visual system. With four HDMI inputs and one HDMI output, this device enables users to seamlessly switch between multiple HDMI-enabled devices, such as game consoles, media players, or computers, without the need to swap cables. Offering a video bandwidth of up to 18Gbps, it supports high-definition resolutions including 4K at 60Hz and 2K at 60Hz/144Hz, making it a top choice for high-end multimedia setups.

In addition to its remarkable video performance, the VLKV-H2041 supports a wide range of audio formats, including Dolby Atmos, DTS:X, and LPCM, providing an immersive surround sound experience. It also features HDR support, including HDR10, Dolby Vision, and HLG, ensuring that you enjoy stunning picture quality with deep contrasts and vibrant colors. Whether you're streaming movies, playing games, or enjoying music, the VLKV-H2041 provides both crystal-clear audio and visual performance with zero latency, ensuring smooth playback for all your media.

Equipped with CEC support, the VLKV-H2041 allows for simple, intuitive control of connected devices via HDMI. Its sleek, compact design, housed in a durable black metal enclosure, ensures long-lasting performance while fitting seamlessly into your AV rack or entertainment system. With low power consumption, minimal standby power usage, and wide operating temperature range, the VLKV-H2041 is engineered to work efficiently in various environments. Ideal for both home and professional use, it is the perfect tool to centralize and control all your HDMI devices with ease.

Key Features

• HDMI 2.0 compliance for high-resolution video output
• Supports up to 4K@60Hz, 2K@60Hz/144Hz video resolution
• Zero latency for both video and audio for smooth, uninterrupted playback
• Supports HDR10, Dolby Vision, and HLG for vibrant and dynamic visuals
• Wide audio format support including Dolby Atmos, DTS:X, and DSD
• CEC support for easy device control via HDMI
• 4 HDMI inputs and 1 HDMI output for flexible connectivity
• Compact metal enclosure with a sleek black finish

Technical Specifications

HDMI Compliance: HDMI 2.0
HDCP Compliance: HDCP 2.3
Video Bandwidth: 18Gbps
Audio Latency: No Latency
Video Latency: No Latency
Video Resolution: Up to 4K@60Hz, 2K@60Hz/144Hz
IR Level: 5Vp-p
IR Frequency: Fixed frequency 38KHz
Color Space: RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Color Depth: 8/10/12bit
HDR: HDR, HDR10, HDR10+, Dolby Vision, HLG
CEC: Support
Audio Formats: HDMI IN/OUT: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DTS:X, DSD; L/R OUT: PCM 2.0CH
ESD Protection: IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)

Input Ports:
- 4 x HDMI input [Type A, 19-pin female]
Output Ports:
- 1 x HDMI output [Type A, 19-pin female]
- 1 x L/R audio output [3.5mm Stereo Mini-jack]

Control Ports:
- 1 x RS-232 [3pin-3.81mm phoenix connector]
- 1 x IR EXT [3.5mm Stereo Mini-jack]
- 4 x USB HOST [USB Type B]
- 4 x USB DEVICES [USB Type A]

Housing: Metal Enclosure
Color: Black
Dimensions: 10.63" [W] x 3.94" [D] x 1.18" [H]
Weight: 1.67 lbs
Power Supply: Input: AC 100 - 240V 50/60Hz; Output: DC 12V/1A (US/EU standard, CE/FCC/UL certified)
Power Consumption: Typical value: 5.28W; Standby mode: 0.72W
Operating Temperature: 32°F ~ 104°F (0°C ~ 40°C)
Storage Temperature: -4°F ~ 140°F (-20°C ~ 60°C)
Relative Humidity: 20 - 90% RH (No condensation)

What's Included

• 1 x VigilLink VLKV-H2041 4-Port HDMI 2.0 Switcher
• 1 x Power Adapter
• 1 x User Manual
