BZBGEAR BG-8K-DA12 1x2 8K UHD HDMI 2.1 Splitter
The BZBGEAR BG-8K-DA12 is a cutting-edge 1x2 HDMI splitter designed to deliver unparalleled video performance for home theaters, gaming setups, and professional AV applications. Boasting support for HDMI 2.1, this device allows seamless transmission of ultra-high-definition content up to 8K@60Hz and 4K@120Hz with 4:4:4 chroma subsampling, ensuring pristine video quality and vibrant colors. Whether you're enjoying Dolby Vision or HDR10+, the BG-8K-DA12 delivers exceptional clarity and depth in every frame.
Engineered with a robust metal enclosure, this splitter offers reliable performance and excellent durability, making it ideal for demanding environments. Its advanced audio compatibility includes Dolby Atmos, DTS-HD Master Audio, and LPCM formats, allowing you to experience immersive soundscapes that complement its stunning visuals. The BG-8K-DA12 also supports a variety of HDR formats, including HDR, HDR10, and HLG, making it versatile for a wide range of devices and content types.
Designed with convenience in mind, the BG-8K-DA12 features a compact form factor that fits effortlessly into tight spaces. The device includes ESD protection for enhanced reliability and offers a USB Type-C port for easy firmware updates, ensuring it stays compatible with the latest HDMI standards. With recommended HDMI cable lengths of up to 39 feet for 4K and up to 10 feet for 8K, the BG-8K-DA12 delivers dependable signal transmission across various setups.
Key Features
- Supports up to 8K@60Hz and 4K@120Hz with 4:4:4 chroma subsampling.
- Compatible with HDMI 2.1 and HDCP 2.3 for future-proof performance.
- Extensive HDR support including HDR10, HDR10+, Dolby Vision, and HLG.
- Advanced audio formats such as Dolby Atmos, DTS-HD Master Audio, and LPCM.
- Compact metal enclosure for durability and efficient cooling.
- USB Type-C port for firmware updates.
- ESD protection ensures reliable operation in various environments.
Technical Specifications
HDMI Compliance: HDMI 2.1
HDCP Compliance: HDCP 2.3
Video Bandwidth: 48Gbps FRL and 18Gbps TMDS
Video Resolution: Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit
Color Depth: 8/10/12bit
Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Audio Formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
HDR: HDR, HDR10, HDR10+, Dolby Vision, HLG
ESD Protection: IEC 61000-4-2: Ā±8kV (Air-gap discharge) & Ā±4kV (Contact discharge)
Connection:
Input: 1 Ć HDMI IN [Type A, 19-pin female]
Output: 2 Ć HDMI OUT [Type A, 19-pin female]
Control: 1 Ć SERVICE [USB Type C, Update port]
Mechanical:
Housing: Metal Enclosure
Color: Black
Dimensions: 3.7in x 2.7in x 0.71in
Weight: 0.39 lbs
Power Supply:
Input: AC 100-240V 50/60Hz
Output: DC 5V/2A (US/EU standards, CE/FCC/UL certified)
Power Consumption: 4.3W (Max)
Operating Environment:
Operation Temperature: 32Ā°F ~ 104Ā°F
Storage Temperature: -4Ā°F ~ 140Ā°F
Relative Humidity: 20~90% RH (non-condensing)
Recommended HDMI Cable:
Video Resolution: 8K@60Hz (10ft), 4K@60Hz (26ft), 4K@24Hz (39ft), 1080P (49ft)
The use of āPremium High-Speed HDMIā cables is highly recommended.
Whatās Included
- 1x 48Gbps 1x2 Splitter
- 1x 5V/2A Multinational Power Supply
- 1x User Manual
