BG-DA-14 HDMI 1x4 Splitter - High-Performance 18Gbps HDMI Splitter
The BG-DA-14 HDMI 1x4 Splitter by BZB Gear is a premium solution designed for seamless distribution of HDMI signals across multiple displays. Perfect for both professional and personal settings, this HDMI splitter supports a wide range of resolutions, including stunning 4K Ultra HD, and delivers 18Gbps bandwidth to ensure crystal-clear visuals with no loss in quality. With one input and four output ports, the BG-DA-14 is ideal for scenarios where duplicating HDMI sources is required, such as digital signage, presentations, and home entertainment systems.
Engineered for reliability, this compact and durable splitter boasts full 18Gbps bandwidth, making it capable of handling high-definition video formats with resolutions up to 4K at 60Hz. The device provides ESD (Electrostatic Discharge) protection for stability, safeguarding against potential damage from electrostatic interference. With a robust metal chassis and compact design, this splitter can easily fit into most setups, offering high-end performance in a space-saving format.
Installing the BG-DA-14 HDMI splitter is straightforward. Simply connect your HDMI source device to the input port, then attach your displays to the output ports. The device requires minimal configuration, allowing you to enjoy high-quality HDMI splitting without the hassle of complex setup. Whether in a professional A/V setting or a high-end home theater system, the BG-DA-14 is designed to offer dependable performance and impressive video quality.
Key Features
- Supports up to 4 displays from a single HDMI source with 18Gbps bandwidth for high-definition video clarity.
- Handles resolutions up to 4K at 60Hz, providing exceptional picture quality on all connected displays.
- Built-in ESD protection ensures the device remains stable and free from interference.
- Compact and durable metal chassis, designed for efficient space use and long-lasting performance.
- Compatible with a wide range of devices, from Blu-ray players and gaming consoles to streaming devices and PCs.
Technical Specifications
Video Bandwidth: 600MHz/18Gbps
Input Ports: 1x HDMI Type A [19-pin female]
Output Ports: 4x HDMI Type A [19-pin female]
Output Resolution: 480i ~ 1080p@50/60, 4Kx2K@24/30, 4Kx2K@60Hz
ESD Protection: Human Body model:
Ā Ā Ā Ā±8kV (Air-gap discharge),
Ā Ā Ā Ā±4kV (Contact discharge)
Power Supply: 5V/1A DC (US/EU standards, CE/FCC/UL certified)
Dimensions: 2.5" (W) x 6.4ā (D) x 0.6" (H) [63mm (W) x 163mm (D) x 16mm (H)]
Weight: 0.57lbs [260g]
Chassis Material: Metal
Silkscreen Color: Black
Operating Temperature: 32Ā°F ~ 104Ā°F / 0Ā°C ~ 40Ā°C
Storage Temperature: -4Ā°F ~ 140Ā°F / -20Ā°C ~ 60Ā°C
Relative Humidity: 20~90% RH (non-condensing)
Power Consumption: 2W
