KanexPro SP-HD1X44K 4K HDMI 4-Port Splitter

The KanexPro 1x4 HDMI Splitter is a 4K@30Hz compliant distribution amplifier which lets you duplicate one HDMI source to four displays without losing signal integrity and resolution. The Ultra HD 4K format on the HDMI splitter ensures astounding picture quality, four times the resolution of high-definition 1080p. This HDCP compliant splitter is also backward compatible with previous HDMI revisions, supporting 1080p / 720p HDMI video resolution devices. Even if you don't require 4K video today, it ensures you'll be ready to take advantage of tomorrow's display technology.

Key Features

• Distribute high-resolution HDMI signals to four Ultra HD displays
• Supports 4Kx2K resolution
• Supports full HD 1080p (1920 x 1080@60Hz)
• Computer resolution up to WUXGA (1920 x1200@60Hz)
• EDID mode for copying the same resolution to input port
• HDCP compliant
• Supports latest HDMI High Speed Specifications
• Supports 12-bit per channel (36-bit all channel) Deep color
• Front USB ports for firmware update
• Compact metal enclosure

Technical Specifications

Signal Inputs/Output
Input DDC Signal: 5 volts p-p (TTL)
Maximum Single Link Range: 4K x 2K@30Hz
Output Video: HDMI 1.4 with full HD 1080p, 1920x1200, 720p, 3D and 4Kx2K + HDCP
Operating Frequency
Vertical Frequency Range: 50/60Hz
Video Amplifier Bandwidth: 2.97 Gbps
Resolutions (HDTV)
Interlaced (50&60Hz): 480i, 576i, and 1080i
Progressive (50&60Hz): 480p, 576p, 720p, 1080p, and 4Kx2K@30Hz
Power Requirements
External Power Supply: 5V DC@ 1A
Power consumption (Max): 5W
Mechanical
Size (L-W-H): 5.7"x2.7"x0.98"
Weight: 0.66 lbs
Environment
Operating Temperature: 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
Package Contents:
HDMI Splitter
5V, 1A DC power supply
Manual
