Audio-Technica CPB CP Beam Antenna for IEMs, Wireless Microphone Systems

Audio-Technica CPB CP Beam Antenna for IEMs, Wireless Microphone Systems

The Audio-Technica CPB CP Beam Antenna is a lightweight, circularly polarized beam antenna that operates within a frequency range of 470 to 698 MHz. This versatile antenna is designed to be compatible with in-ear monitors (IEMs), wireless microphone systems, and other ultra-high frequency (UHF) communication devices. Thanks to its unique folding design, the CP Beam Antenna is not only easy to set up but also incredibly convenient to transport and store. Weighing in at just 2.5 lbs, it fits perfectly within a 2RU rack drawer and compresses to a compact size, making it an excellent choice for professionals on the go.

Utilizing the CP Beam Antenna is straightforward: simply disconnect the straps, extend the antenna, and connect a coaxial cable (not included) to your receiver, transmitter, or antenna combiner. With the ability to provide up to 9 dB of antenna gain, this antenna is a powerful tool to enhance your signal strength. It can be mounted easily to threads of 1/4"-20, 3/8"-16, or 5/8"-27, offering flexibility for various setups.

Whether you're in a live performance environment or a broadcasting scenario, the Audio-Technica CPB CP Beam Antenna is engineered to deliver reliable, high-quality performance, ensuring you maintain a strong and stable signal throughout your operations.

Key Features

• Lightweight, circularly polarized beam antenna (470-698 MHz)
• Unique folding design allows antenna to be collapsed for storage and transport
• Compatible with IEMs, wireless microphone systems, and other UHF communication devices
• 63 x 70 degree beam angle
• Provides up to 9 dB of antenna gain

Specifications

• Operating frequency: 470 to 698 MHz
• Bandwidth: 228 MHz
• Average return loss: -13.15 dB
• Impedance: 50 ohms
• Pattern type: Beam
• Polarization: RHCP
• Beam width: Azimuth X: 63 degrees, Azimuth Y: 70 degrees
• F/B ratio: Azimuth X: -10 dB, Azimuth Y: -9 dB
• F/S ratio: Azimuth X: -12 dB, Azimuth Y: -12 dB
• Squint: Azimuth Y: <2 dB
• Gain: Azimuth Y: 9 dB
• Dimensions: 355 mm (14.0") W x 355 mm (14.0") H
• Weight: 1.1 kg (2.4 lbs)
• Mount threads: 1/4"-20, 3/8"-16 or 5/8"-27
• Operating temperature range: -23°C to +54°C (-9°F to +129°F)
• Connector: BNC female

Package Contents

• Audio-Technica CPB CP Beam Antenna
• Instruction manual
• Mounting accessories
