Kramer 3KHVE2i HDb3000 HDMI RF/IP Media Module Blade

This blade encodes two unencrypted HDMI sources (up to 1080p with embedded or analog audio) into MPEG-2 for simultaneous QAM/DVB-T/C RF modulation and IP streaming. Designed for hot-swappable use in the HDb3000 chassis, it supports closed captioning and includes independent analog audio delay matching.

Compact and rack-optimized, the module integrates front- and rear-mounted LCD/IP configuration with support via ZeeVee Maestro. It's ideal for HD video distribution in hospitality, enterprise, and broadcast headend applications.

Key Features

  • 2 × HDMI inputs (up to 1080p) with embedded/analog audio
  • Dual-path output: RF QAM/DVB-T/C and UDP/IP streaming
  • Independent analog audio delay matching
  • Closed-captioning support via composite override
  • Delivers up to 24 HD channels per chassis
  • Hot-swappable, 3‑RU rack integration with redundant cooling
  • Configuration via front-panel LCD or Zeppelin Maestro network GUI
  • Wide-range AC supply: 100-240 VAC, IEC C14, 300 W chassis capacity

Technical Specifications

  • Dimensions: 5″ × 0.85″ × 11″ (127 × 21 × 279 mm)
  • Product Weight: 1.10 lb (0.50 kg)
  • Operating Temperature: 32-113 °F (0-45 °C)
  • Chassis Power: 100-240 VAC, 300 W IEC C14
  • Cooling: Four hot-swappable N+1 fans, front inlet/rear exhaust
  • RF Output: QAM‑64/256 or DVB‑T/C, 54-864 MHz range, 13-34 dBmV, MER >39 dB
  • IP Output: 10/100 Mb Ethernet, DHCP/static IP
  • Encoding: MPEG‑2, ~18 Mb/s per channel, latency 200-400 ms
  • Audio: Embedded HDMI, plus analog L/R with delay-matching
  • CC Support: Closed captioning via composite input

What's Included

  • 3KHVE2i module (pre-loaded firmware)
  • Access to ZeeVee Maestro control software
