AJA HA5 12G-SDI to HDMI 2.0 Conversion with ST Fiber Receiver
AJA | SKU: AJA-HA512GTST
Authorized Dealer
1
of
3
Loading...
Newly Added
$1,55000
Free Shipping
Unit price
/
Unavailable
Estimated Shipping Widget will be displayed here!
Enjoy free standard shipping on all orders over $99. Please note that this offer excludes oversized, overweight, special orders, custom products, and items with minimal profitability.
Orders placed between Monday - Friday before
1:00 PM PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Orders placed between Monday - Friday before
1:00 PM PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Condition: New
Description
AJA HA5 12G-SDI to HDMI 2.0 Conversion with ST Fiber Receiver
This AJA HA5 model converts HDMI 2.0 sources to 12G-SDI and adds an ST fiber output for carrying the signal over long distances, up to 10 km on single mode fiber, with the SFP shipping pre-installed. It serves installations and live productions that need to land HDMI 4K/UltraHD sources into SDI infrastructure while extending the feed across a building or campus.
HDMI 2.0b input is supported up to 4K/UltraHD 60p at 4:4:4, 4:2:2, or 4:2:0, with 12-bit workflow support and a second mirrored 12G-SDI output. EDID emulation covers low and high frame rates up to UHDp60, HDR Infoframe data is reported in real time with metadata pass-through or override, and embedded audio can come from the HDMI source or a two-channel analog RCA input, including pass-through of AC-3 and E-AC-3 with DD+ Atmos.
Key Features
- Converts HDMI 2.0b up to 4K/UltraHD 60p to 12G-SDI with a second mirrored output
- Single channel ST fiber link extends signals up to 10 km over single mode
- Ships with FiberST-1T-12G SFP installed
- Supports 4:4:4/4:2:2/4:2:0 inputs and 12-bit workflows
- EDID LFR and HFR emulation up to UHDp60
- Real-time HDR Infoframe reporting with metadata pass-through or override
- Embeds HDMI or analog RCA audio; passes AC-3 and E-AC-3 including DD+ Atmos
Specifications
- (4K) 4096x2160p
- (UltraHD) 3840x2160p
- (2K) 2048x1080p
- (HD) 1920x1080p
- (HD) 1920x1080p
- (HD) 1280x720p
- (SD) 720x576p
- (SD) 720x576i
- (SD) 720x480p
- (SD) 720x480i
- 1x HDMI Type A connector, HDMI v2.0b
- HDR Infoframe decoder as defined in CTA-861.3 and HDMI v2.0b
- HDR VPID generation with pass-through or override for
- Colorimetry and Transfer Characteristic
- YCbCr 4:2:2/4:4:4/4:2:0
- RGB 4:4:4, SMPTE or Full level
- 24, 30, or 36 Bits Per Pixel (HFR 4K/UltraHD 4:4:4 limited to 24 BPP)
- (4K) 4096x2160p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
- (UltraHD) 3840x2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
- (2K) 2048x1080p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
- (HD) 1920x1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
- (HD) 1920x1080i 50, 59.94, 60
- (HD) 1280x720p 50, 59.94, 60
- (SD) 720x576p 50
- (SD) 720x576i 25
- (SD) 720x480p 59.94
- (SD) 720x480i 29.97
- HDCP Decryption
- Not supported. By definition, SDI outputs are unencrypted.
- 1x 12G-SDI BNC, SMPTE 259/292/424/2081/2082
- YCbCr 4:2:2/4:4:4
- RGB 4:4:4, SMPTE or Full level
- 10-bit, 12-bit*
- 1x 12G-SDI
- (4K) 4096x2160p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
- (UltraHD) 3840x2160p 23.98, 24, 25, 29.97, 30,50, 59.94, 60 1x 6 Gb SDI
- (4K) 4096x2160p 23.98, 24, 25, 29.97, 30
- (UltraHD) 3840x2160p 23.98, 24, 25, 29.97, 30 1x 3 Gb SDI (Level A or B Dual Link)
- (2K) 2048x1080p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
- (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30
- (HD) 1920x1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
- (HD) 1920x1080PsF 23.98, 24, 25, 29.97, 30
- (HD) 1920x1080i 50, 59.94, 60
- (HD) 1280x720p** 50, 59.94, 60
- 1x 1.5 Gb SDI
- (2K) 2048x1080p 23.98, 24, 25, 29.97, 30
- (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30
- (HD) 1920x1080p 23.98, 24, 25, 29.97, 30
- (HD) 1920x1080PsF 23.98, 24, 25, 29.97, 30
- (HD) 1920x1080i 50, 59.94, 60
- (HD) 1280x720p 50, 59.94, 60
- 1x 270 Mb SDI
- (SD) 625i 50
- (SD) 525i 59.94
- 1x 12G-SDI Fiber ST connector, SMPTE
- 297/259/292/424/2081/2082
- Nominal Wavelength: Tx 1260 nm (min), 1310 nm (typ), 1360 nm
- (max)
- Optical Power: -5 dBm (min), 2 dBm (max)
- Extinction Ratio: 3.5 dB (min)
- Audio Pass-Through Formats
- PCM
- Dolby Digital (AC-3)
- Dolby Digital Plus (E-AC-3), including Atmos Immersive Sound (JOC)
- Audio Input Digital
- HDMI embedded audio, 24-bit, 8-channel
- Video Formats
- Note: Raster and Frame Rate Dependent, please see HA5-12G Video Formats in the Download / Documents section of the website product page.
- Video Input Digital
- Video Output Digital
- Video Output Digital - Additional for HA5-12G-T-ST Only
- Audio Input Analog: 2x RCA style connector, 2-channel -10dBu (nominal)
- Audio Output Digital: SDI embedded audio, 24-bit (SD limited to 20-bit), 16-channel; User Interface; USB port used with supplied cable and Mini-Config software application to configure and view device status via Mac or Windows
- Size (w x d x h): 4.6" x 4.02" x 0.9" (116.84 x 102.11 x 22.86 mm)
- Weight: 0.5 lb (0.3 kg)
- Power: 5-16VDC regulated, 11 watts, universal power supply included; AC Adapter: 100-240VAC, 50/60 Hz, universal input
- Environment: Safe Operating Temperature: 0 to 40 C (32 to 104 F); Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F); Operating Relative Humidity: 10-90% noncondensing; Operating Altitude: <3,000 meters (<10,000 feet)
- *HA5-12G, HA5-12G-T, and HA5-12G-T-ST each use approximately 12 watts of power and convection cooling. It will be warm to the touch, which is normal. When installing the unit, mount in a location where it has access to air for proper cooling. Do not stack the HA5-12G converters with other Mini-Converters.
What's Included
- HA5 12G-SDI to HDMI 2.0 Conversion with ST Fiber Receiver
