Appsys ProAudio Flexiverter FLX-RAVENNA/SRC RAVENNA Converter with SRC
The Appsys ProAudio FLX-RAVENNA/SRC RAVENNA Converter is a compact RAVENNA-to-anything converter with built-in 64x64-channel sample rate conversion. It converts 64x64 channels of RAVENNA to any supported protocol installed in the AUX slot, while adding ST2110 and AES67 support for professional networked audio systems.
Designed for broadcast, live production, studio, and installed audio networks, this RAVENNA converter with SRC helps engineers connect separate audio formats without rebuilding the entire signal chain. Use it to buy a RAVENNA converter with AES67 support, bridge RAVENNA to Dante through the proper AUX card, or extend larger Flexiverter and MVR-mkII systems.
The FLX-RAVENNA/SRC uses the proven Merging/Sennheiser ZMAN module and supports professional routing workflows through its AUX port, FlexLink port, USB remote control, and triple-redundant power supply architecture. Its bidirectional SRC can be bypassed when sample rate conversion is not needed.
Key Features
- RAVENNA Conversion: Converts 64x64 channels of RAVENNA to any supported format installed through the AUX slot.
- Built-In SRC: 64x64-channel bidirectional sample rate conversion supports mixed-clock digital audio systems.
- ST2110 and AES67 Support: Built-in networked audio compatibility supports modern broadcast and IP audio workflows.
- Dual RAVENNA Ports: Two EtherCON RAVENNA ports provide professional network connectivity.
- AUX Card Expansion: Accepts compatible AUX cards for conversion to formats such as Dante or RAVENNA bridging.
- Clock-Domain Separation: Works with AUX-RAVENNA as a RAVENNA-to-RAVENNA bridge with full network and clock-domain separation.
- FlexLink Integration: Transfers 192 channels of audio, clock, and power with low latency for larger systems.
- USB Remote Control: Offers web-based USB control with no software required, plus UART command-line access.
Technical Specifications
- Product Type: RAVENNA-to-anything digital audio converter with sample rate conversion
- Model: FLX-RAVENNA/SRC
- Built-In Audio Format: RAVENNA
- Network Audio Support: RAVENNA, ST2110, AES67
- RAVENNA Ports: 2 x EtherCON ports
- Module Platform: Merging/Sennheiser ZMAN module
- Conversion Capacity: 64x64 channels of RAVENNA to supported AUX-slot protocol
- Sample Rate Conversion: 64x64-channel bidirectional SRC, bypassable
- Supported Sample Rates: 44.1 to 192 kHz on either side
- Performance: Greater than 120 dB THD+N; greater than 134 dB DNR
- Expansion: AUX port accepts compatible AUX cards as conversion source or destination
- RAVENNA Bridge Support: Supports RAVENNA-to-RAVENNA bridging with AUX-RAVENNA card
- FlexLink: Bidirectional transfer of 192 channels of audio, clock, and power
- MVR-mkII Integration: Supports true channel-wise routing of all available channels when connected to MVR-mkII
- Remote Control: USB web remote or UART command line
- Power Supply: Triple-redundant power supply support
