ATEN CS782DP 2-Port USB DisplayPort/Audio KVM Switch
ATEN CS782DP 2-Port USB DisplayPort/Audio KVM Switch
Free Shipping
ATEN CS782DP 2-Port USB DisplayPort/Audio KVM Switch
With the ever-growing demand for higher video quality and the evolution of DisplayPort technology, 4K-enabled computers and displays are now widely adopted in visually-intensive and commercial applications. Offering up to 4K resolution, the ATEN CS782DP is at home amongst these demanding scenarios and technological advancements.
The ATEN CS782DP 2-Port USB DisplayPort KVM Switch features 4K video resolution and allows users to access two 4K-enabled computers from a single USB keyboard, USB mouse, and DisplayPort video console.
Doing so with ease, the CS782DP provides three convenient switching methods - using a remote port selector, mouse, or hotkeys for flexible access to any computer connected to the installation. The product even provides premium audio support for a complete multimedia solution. To round off the entire experience, the streamlined, space-saving design of CS782DP also makes it ideal for any working environment.
With its rich feature set, the CS782DP is designed to surpass all requirements in graphic design, animation, and video-editing applications.
Key Features
- One DisplayPort video console controls two USB computers
- DisplayPort 1.2 compliant; HDCP compliant
- Computer selection via remote port selector, hotkeys, and USB mouse1
- Superior video quality - 4K UHD (3840 Ć 2160 @ 60 Hz) and 4K DCI (4096 x 2160 @ 60 Hz)
- Supports MST (Multi-Stream Transport)2, enabling multiple monitors to be used via a single DisplayPort connector
- Multiplatform support - Windows, Mac, Sun, and Linux
- Compatible with widescreen LCD monitors
- Power on detection - if either of the computers is powered off, the CS782DP will automatically switch to the other computer
- Audio-enabled - full bass response provides a rich experience for 2.1 channel surround sound systems
- Supports HD Audio3 through DisplayPort playback
- Independent switching of the KVM and Audio focus3 allows convenient multi-tasking
- Supports multimedia keyboards
- Supports wireless keyboards and mice
- Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
- Mac/Sun keyboard support and emulation4
- USB 2.0 mouse port can be used for USB hub and USB peripheral sharing5
- Bus-Powered
- Firmware upgradable
Technical Specifications
Computer Connections
2
Port Selection
Hotkey, Mouse, Remote Port Selector
Connectors
Console Ports
2 x USB Type A Female
1 x DisplayPort Female (Black)
1 x 3.5mm Audio Jack Female (Green)
KVM (Computer) Ports
2 x USB Type B Female
2 x DisplayPort Female (Black)
2 x 3.5mm Audio Jack Female (Green)
Remote Port Selector
1 x 2.5mm Audio Jack Female
LEDs
KVM
2 (White)
Emulation
Keyboard / Mouse
USB
Video
4096 x 2160 @ 60Hz
Scan Interval
3, 5, 10, 20 seconds (Default: 5 seconds)
Power Consumption
DC5V:2. 18W:23BTU
Environmental
Operating Temperature
0 - 50Ā°C
Storage Temperature
-20 - 60Ā°C
Humidity
0 - 80% RH, Non-condensing
Physical Properties
Housing
Plastic
Weight
0.12 kg (0.26 lb)
Dimensions (L x W x H)
9.37 x 9.30 x 2.68 cm
(3.69 x 3.66 x 1.06 in.)
Note
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
