Barco Clickshare R9461811US ClickShare Hub Core and Control Panel Kit

Barco R9461811US ClickShare Hub Core and Control Panel Kit

The Barco R9461811US ClickShare Hub Core and Control Panel Kit is a modular wireless video conferencing room system for Microsoft Teams Rooms. It combines a Hub Core Base Unit, responsive 10.1-inch Control Panel, and fifth-generation ClickShare Button to provide one-touch meeting control and wireless 4K content sharing in professional conference spaces.

Designed for small meeting rooms and flexible collaboration environments, the system supports scheduled Microsoft Teams meetings plus wireless BYOD access to other conferencing platforms. The included ClickShare Button uses Wi-Fi 6E and USB-C DisplayPort for convenient guest presentation, while the dedicated Control Panel gives participants a centralized interface for launching and managing meetings.

The Hub Core runs on the Microsoft Device Ecosystem Platform and integrates with Barco XMS Cloud for centralized management and reporting. Enterprise deployment features include wired LAN connectivity, Bluetooth 5.3, multi-band wireless networking, Kensington security provisions, and FCC/CE certifications. When combined with compatible certified AV devices, the Hub Core operates as part of a Microsoft Teams-certified room solution.

Key Features

• Microsoft Teams Rooms Platform: Provides a modular room-system foundation for scheduled hybrid meetings and professional collaboration spaces.
• Wireless 4K Presentation: Shares high-resolution content through the included fifth-generation ClickShare Button.
• Wireless BYOD: Lets laptop users access compatible room AV equipment for additional conferencing platforms.
• 10.1-Inch Control Panel: Provides a dedicated touchscreen interface for fast meeting startup and room control.
• Wi-Fi 6E ClickShare Button: Supports modern wireless connectivity and USB-C DisplayPort for straightforward guest presentation.
• Cloud Management: Supports Barco XMS Cloud for centralized device management and reporting.
• Flexible AV Connectivity: Provides HDMI, USB-A, USB-C, DisplayPort Alt Mode, and Gigabit Ethernet connections.
• Professional Security: Uses the Microsoft Device Ecosystem Platform and includes Kensington lock provisions on key components.

Technical Specifications

Hub Core System

• Brand: Barco
• Article Number: R9461811US
• Product: ClickShare Hub Core and Control Panel Kit
• Region: US
• System Type: Modular wireless video conferencing room system
• Operating System: Android on Microsoft Device Ecosystem Platform (MDEP)
• Microsoft Teams Rooms License Required: Yes
• ClickShare App: Desktop
• ClickShare Buttons: 1 fifth-generation ClickShare Button
• Maximum Simultaneous On-Screen Sources: 1
• Video Output: HDMI 2.0 up to 5120 x 2160 at 30 Hz
• Control Panel Video Output: 1280 x 800 at 60 Hz via DisplayPort 1.4
• Video Input: HDMI 2.0 up to 3840 x 2160 at 30 Hz
• Audio Outputs: USB-A 2.0/3.0, USB-C 2.0/3.0, HDMI 2.0
• Wireless Protocols: IEEE 802.11 a/b/g/n/ac/ax/be and Bluetooth 5.3
• Wireless Frequency Bands: 2.4 GHz, 5 GHz, and 6 GHz DBS/HBS; DFS support varies by country
• Maximum Button-to-Base-Unit Range: 100 ft
• Network Connection: 1 Gb Ethernet LAN
• Management and Reporting: XMS Cloud
• Anti-Theft Provision: Kensington lock
• Certifications: FCC, CE
• Eco Label: Barco Eco Label A+
• Warranty: 3 years standard
• Operating Temperature: 32°F to 104°F; maximum 95°F at 9,842.5 ft altitude
• Storage Temperature: -4°F to 140°F
• Operating Humidity: 0% to 85% relative humidity, non-condensing
• Storage Humidity: 0% to 90% relative humidity, non-condensing
• Noise Level: Maximum 25 dBA below 86°F; maximum 30 dBA above 86°F
• Maximum Power Consumption: 140 W operational
• Power Supply: External USB-C charger supporting 100 W PD3.0 SPR or 180 W PD3.1 EPR
• Hub Core Dimensions (H x W x D): 1.5" x 7.1" x 7.1"
• Hub Core Weight: 1.6 lb

Computer Requirements for ClickShare App

• Minimum Windows: Intel Core i3 or AMD Ryzen 5 processor, 8 GB RAM, Windows 10 20H2 or later
• Recommended Windows: Intel Core i5/Ultra 5 or AMD Ryzen 7 processor, 8 GB RAM, latest Windows 11 build
• Minimum macOS: Intel Core i3 or Apple Silicon M1, 8 GB RAM, macOS 11 Big Sur
• Recommended macOS: Apple Silicon M3, 8 GB RAM, latest macOS build

Hub Core Connections

• Rear Ethernet: 1 x 1 Gb LAN
• Rear Power: 1 x USB-C Power Delivery 3.1 EPR input
• Rear HDMI: 1 x HDMI 2.0 output
• Rear USB-A: 1 x USB-A 2.0/3.0
• Rear USB-C: 1 x USB-C 2.0/3.0
• Rear USB-C Device/Video: 1 x USB-C 2.0/3.0 Device with USB-C DisplayPort output
• Rear USB-C Video: 1 x USB-C 2.0 with USB-C DisplayPort output
• Front USB-C: 1 x USB-C 2.0/3.0

ClickShare Control Panel

• Display: 10.1-inch projected capacitive touchscreen
• Touch Support: Up to 4 simultaneous touch points
• Display Coatings: Anti-fingerprint and anti-glare
• Resolution: 1280 x 800 at 60 Hz
• Brightness: 300 nits
• Contrast Ratio: 1000:1
• Viewing Angle: 80° up, down, left, and right
• Human Detection Sensor: Detects movement within approximately 6.6 ft across a 90° field of view
• Connection: USB Type-C 2.0 with DisplayPort Alt Mode and PD3.0
• Anti-Theft Provision: Kensington lock
• Operating Temperature: 32°F to 104°F
• Storage Temperature: -4°F to 140°F
• Operating Humidity: 0% to 85% relative humidity, non-condensing
• Storage Humidity: 0% to 90% relative humidity, non-condensing
• Power: Powered over USB from the connected Base Unit
• Maximum Operational Power Consumption: 7.3 W
• Standby Power Consumption: Less than 0.5 W
• Dimensions (H x W x D): 10" x 7.4" x 3"
• Weight: 1.8 lb

USB-C AOC Cable

• Cable Length: 32.8 ft
• Cable Diameter: 0.2"
• Interface: USB Type-C 3.2 Gen 1, DisplayPort 1.4
• Power Delivery: 20 W
• Permanent Bend Radius: 2.4"
• Temporary Bend Radius: 1.2"
• Operating Temperature: 14°F to 140°F
• Storage Temperature: -4°F to 158°F
• Operating and Storage Humidity: 0% to 85% relative humidity, non-condensing
• Flame Rating: VW-1, non-plenum

Power Supply

• AC Input: 100-240 V AC, 50-60 Hz, 2.4 A
• Maximum DC Output: 180 W
• Supported DC Outputs: 36 V/5 A, 28 V/5 A, 20 V/5 A, 15 V/3 A, 9 V/3 A, 5 V/3 A
• Output Connector: USB Type-C
• AC Input Connector: IEC60320-C6
• Energy Efficiency: DOE Level VI compliant
• Maximum Altitude: 16,404.2 ft
• DC Cable Length: 4.9 ft

Power Cord

• Color: Black
• Length: 1.6 ft
• Connector: IEC60320-C5

What's In the Box

• ClickShare Hub Core Base Unit
• ClickShare Button 5th Generation
• Mounting Disc
• Safety Manual
• Quick Setup Guides
• ClickShare Control Panel
• 32.8 ft 20 W USB-C AOC Cable
• L-Shape Mounting Plate
• Round Base
• Screw Pack
• USB-C Cable Lock Kit
• Power Cord
• Power Supply
