Description
The Blackmagic Cloud Store Ultra 24TB is an extremely high-performance shared network storage solution built for demanding broadcast, post-production, and live-production workflows. Housed in a compact 1RU rackmount chassis, it pairs a 12-card RAID 0 flash memory core with M.2 NVMe SSD technology to deliver the sustained throughput modern teams need for high-resolution and ISO-recorded media. With dual 100G QSFP28 Ethernet ports, the Cloud Store Ultra can serve a HyperDeck Extreme ISO recorder on one network while simultaneously feeding dozens of local edit workstations on the other, all from a single high-speed flash array.
Designed for reliability in data-center and machine-room environments, the Cloud Store Ultra features server-style front-to-rear cooling, six redundant fans, and two redundant internal power supplies so a single failure never takes storage offline. Each 100G port can be assigned an independent IP address and subnet mask, enabling up to 200G of aggregate bandwidth and load balancing when used with a managed switch, or full network isolation and redundancy when run as two separate networks. RAID 5 reformatting adds parity-based data protection, allowing files to be rebuilt after replacing a card.
Blackmagic Cloud Sync lets teams distribute and synchronize files globally, turning local storage into a connected part of a worldwide collaborative pipeline. A built-in 2.2 inch LCD with spin knob handles setup and shows storage name, capacity, and usage, while dedicated HDMI and SDI monitor outputs present a real-time visual overview of storage status, bandwidth, connected users, and synchronization activity on any broadcast monitor. Setup and software updates are handled over USB-C using the free Cloud Store Setup utility for macOS and Windows.
Features
- 24TB of high-speed flash storage built on a 12-card RAID 0 M.2 NVMe core for extreme sustained performance
- Two 100G QSFP28 Ethernet ports for up to 200G aggregate bandwidth, load balancing, or dual-network isolation
- RAID 5 support with parity for data protection and card-failure rebuild
- Dual redundant internal power supplies and six redundant fans for data-center reliability
- HDMI and SDI monitor outputs show live storage status, bandwidth, users, and sync activity
- Blackmagic Cloud Sync distributes and synchronizes files globally across collaborating teams
- Built-in 2.2 inch LCD with spin knob and buttons for fast on-unit setup and monitoring
- Compact 1RU chassis with server-style front-to-rear cooling for rack installation
Technical Specifications
- Storage Capacity: 24TB
- Storage Type: M.2 NVMe SSD
- RAID Architecture: 12-card RAID 0 flash core with RAID 5 data-protection support
- 100G Ethernet: 2 x 100G QSFP28
- Management Ethernet: 1 x RJ45, 10/100/1000 BASE-T
- USB-C: 1 x USB-C for setup utility and software updates
- Monitor Outputs: 2 x SDI and 1 x HDMI (1080p50, 1080p59.94, 1080p60)
- Display: Built-in 2.2 inch color LCD with spin knob and 3 buttons
- Power: 2 x 100-240V AC 50/60Hz internal redundant supplies, 2 x IEC C14 inputs
- Cooling: Server-style front-to-rear with 6 redundant fans
- Form Factor: 1 rack unit (1RU)
- Operating Temperature: 5 to 40 C (41 to 104 F)
- Software Compatibility: macOS 15 Sequoia / macOS 26 Tahoe or later, Windows 11
What's Included
- Blackmagic Cloud Store Ultra 24TB unit
- Welcome wallet with QR code for software download
