Blackmagic Design Video Hub 12G Zero Latency Video Router
The Blackmagic Videohub 12G Router is an advanced video routing solution offering zero-latency switching between SD, HD, Ultra HD, and 4K signals. Available in three versatile models — 10x10, 20x20, and 40x40 — it provides flexible I/O options to suit various production needs. Designed for professional broadcast and post-production environments, it supports mixed video formats simultaneously with high-speed 12G-SDI connections. Featuring a 5-inch LCD for monitoring, intuitive routing controls, and redundant power inputs, it ensures reliability and ease of use. Integrated Ethernet and USB-C interfaces allow flexible remote operation across various systems and devices.
Ideal for high-end studios and mobile production units, this router combines powerful signal management with compatibility across a vast range of video standards. Its rugged rackmount design, SDI re-clocking, and support for standards up to 2160p60 make it a future-proof solution for complex video infrastructures. Extensive control options and seamless format auto-switching make it a standout choice for critical broadcast applications.
Key Features:
- Available in 10x10, 20x20, and 40x40 12G-SDI configurations
- Supports 10/100/1000 BASE-T Ethernet control
- SD, HD, Ultra HD, and 4K DCI format compatibility
- SDI re-clocking on all outputs
- Redundant reference input and loop output (Tri-Sync or Black Burst)
- 5-inch built-in color LCD for live video and routing label display
- Built-in router control with 24 direct selection buttons
- USB-C port for direct control and updates
- Supports SDI auto switching between 270Mb, 1.5G, 3G, 6G, 12G, and DVB-ASI
- Control software for Mac and Windows included
Technical Specifications:
SDI Video Inputs: 120
SDI Video Outputs: 120
SDI Rates: DVB-ASI, 270Mb, 1.5G, 3G, 6G, 12G
Video Input Re-Sync: None
SDI Reclocking: On all SDI outputs
Reference Inputs: Tri-Sync or Black Burst
Reference Outputs: Loop output
Ethernet: 10/100/1000 BASE‑T
Computer Interface: USB-C
SD Video Standards: 525i59.94 NTSC, 625i50 PAL
HD Video Standards: 720p50/59.94/60, 1080i50/59.94/60, 1080p23.98-60, 1080PsF23.98-30
2K Video Standards: 2Kp23.98-60 DCI, 2KPsF23.98-30 DCI
Ultra HD Video Standards: 2160p23.98-60
4K Video Standards: 4Kp23.98-60 DCI
SDI Compliance: SMPTE 259M, 292M, 296M, 372M, 424M, 425M Level A/B, 2081-1/10, 2082-10, ITU‑R BT.656, ITU‑R BT.601
SDI Audio Sampling: 48kHz, 24-bit
SDI Video Sampling: YUV 4:2:2 and RGB 4:4:4
SDI Color Precision: 10, 12-bit
SDI Color Space: REC 601, REC 709, REC 2020
SDI Auto Switching: Supported
Built-in Control Panel: 24 direct buttons, 3 menu control buttons, spin knob
External Control Panel: Supports Videohub Smart Control Pro and Videohub Master Control Pro
Software Control: Included for Mac and Windows
Internal Software Upgrade: Via updater application
Operating Systems Supported: Mac 13.0 or later, Windows 10/11
Package Contents:
- Blackmagic Videohub 12G Router
- Welcome booklet with QR code for software download
