BOSS FS-5L Latching Footswitch with LED

BOSS FS-5L Latching Footswitch with LED Indicator

The BOSS FS-5L is a rugged latch-type footswitch designed for hands-free on/off control of compatible BOSS and Roland equipment. Built from durable metal construction, the FS-5L stays engaged after each press and releases on the next — making it ideal for toggling functions that need to remain active. An integrated LED indicates the current active status at a glance.

The FS-5L connects to compatible devices via a standard 1/4-inch mono cable, making it easy to integrate into any existing rig. Its latching behavior is purpose-built for applications where a momentary press-and-hold is impractical — such as activating a looper, switching amp channels, or engaging a rhythm track.

Compatible with a wide range of BOSS compact pedals, Roland guitar amps, rhythm machines, and multi-effects units. Its compact footprint and robust metal housing make it easy to mount on any pedalboard. Two AAA batteries power the LED indicator.

Key Features

• Latch-Type Operation: Stays engaged after each press and releases on the next.
• LED Status Indicator: Built-in LED clearly shows active/bypassed status.
• Rugged Metal Construction: Durable all-metal housing withstands live performance demands.
• Standard 1/4-Inch Connectivity: Connects via ordinary guitar cables — no proprietary connectors required.
• Broad Compatibility: Works with BOSS compact pedals, Roland guitar amps, multi-effects units, and rhythm machines.
• Interlocking Design: Edge construction enables side-by-side interlocking with other BOSS FS-5 footswitches.

Technical Specifications

• Type: Latch (latching)
• Connectors: 1/4-inch phone type jack
• Power Supply: AAA batteries x 2
• Width: 3-13/16 inches
• Depth: 3-9/16 inches
• Height: 1-3/4 inches
• Weight: 0.53 lbs
