BOSS SDE-3 Dual Digital Delay Pedal with Offset Control

BOSS SDE-3 Dual Digital Delay Pedal

The BOSS SDE-3 Dual Digital Delay Pedal brings the core sound and modulation behavior of the Roland SDE-3000 rack delay into a compact stompbox. It provides up to 800 ms of mono or stereo delay, an extended 1600 ms mono mode, variable Offset dual delays, tap tempo, modulation, and flexible output routing.

Designed for guitarists, synth players, studios, and pedalboard rigs, the SDE-3 handles classic single echoes, modulated digital delay, rhythmic repeats, wide stereo effects, and wet/dry setups. Its Offset control adds a second delay line, either 1 to 100 ms longer than the primary delay or synchronized between eighth-note and dotted-eighth subdivisions for tempo-based patterns.

The pedal processes audio at 48 kHz with 24-bit AD conversion using BOSS Adaptive Focus processing and 32-bit DA conversion. Stereo inputs and outputs support panning or discrete stereo delays, while a 3.5 mm TRS MIDI input receives external clock synchronization. Optional footswitches and expression pedals provide additional tap-tempo, hold, and parameter-control options.

Key Features

• SDE-3000-Inspired Delay: Recreates the distinctive digital delay and modulation character of Roland's classic rack processor.
• Variable Offset Control: Adds a secondary delay line for doubled echoes, rhythmic patterns, and expanded stereo textures.
• Extended Delay Range: Provides up to 800 ms in mono or stereo operation and up to 1600 ms in mono.
• Independent Modulation: Dedicated Rate and Depth controls shape movement without requiring menu navigation.
• Hi Cut Control: Reduces high-frequency content to create darker echoes and atmospheric delay textures.
• Flexible Stereo Routing: Supports discrete stereo delay, panning, wet/dry output, and dry-mute configurations.
• Tap Tempo and Carryover: Synchronizes repeats during performance and optionally preserves delay trails when bypassed.
• External Control: Supports footswitches, an expression pedal, and TRS MIDI clock synchronization for expanded operation.

Technical Specifications

• Product Type: Digital delay effects pedal
• Model: SDE-3
• Maximum Delay Time: 800 ms in mono or stereo; 1600 ms in mono
• Secondary Offset Delay: 1 to 100 ms longer than the primary delay in doubled-delay operation
• Rhythmic Offset Range: Eighth-note through dotted-eighth-note subdivisions relative to the primary quarter-note delay
• Stereo Delay Modes: Panning and discrete stereo
• Output Modes: Stereo, wet/dry, and dry mute
• Tap Tempo: Supported
• Carryover: Selectable on or off
• Hold Function: Supported with compatible external control
• Sample Rate: 48 kHz
• AD Conversion: 24-bit plus AF (Adaptive Focus) method
• DA Conversion: 32-bit
• Nominal Input Level: -20 dBu
• Maximum Input Level: +7 dBu
• Input Impedance: 1 megohm
• Nominal Output Level: -20 dBu
• Maximum Output Level: +7 dBu
• Output Impedance: 1 kilohm
• Recommended Load Impedance: 10 kilohms or greater
• Bypass: Buffered bypass
• Controls: Time, Feedback, Level, Depth, Rate, Hi Cut, Offset, pedal switch, Carryover switch
• Indicator: Check indicator for tempo and battery status
• Inputs: Input A/Mono and Input B, 1/4" phone type
• Outputs: Output A/Mono and Output B, 1/4" phone type
• Control Connection: 1 x 1/4" TRS CTL/EXP jack
• MIDI Input: 1 x 3.5 mm stereo miniature phone jack
• MIDI Function: External MIDI clock synchronization
• Power Supply: 9V alkaline battery or optional BOSS PSA-series AC adapter
• Current Draw: 75 mA
• Expected Alkaline Battery Life: Approximately 4.5 hours
• Dimensions (W x D x H): 2.9 x 5.1 x 2.3 in
• Weight: 1 lb including battery
• Compatible Footswitch: BOSS FS-5U
• Compatible Dual Footswitches: BOSS FS-6, FS-7
• Compatible Expression Pedals: BOSS FV-500H, FV-500L, EV-30; Roland EV-5
• Compatible TRS/MIDI Cables: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-3535
• Warranty: 5 years

What's In the Box

• BOSS SDE-3 Dual Digital Delay Pedal
• 9V dry battery
• Safety, important notes, and information leaflet
