Camplex 4K/2K HDMI 2.0 Over Fiber Extender Set with 10G Ethernet and RS-232
The Camplex CMX-FMCH002 4K HDMI 2.0 Fiber Extender Set sends HDMI 2.0 video up to 4K@60Hz 4:4:4 HDR10 over single mode LC fiber. It extends uncompressed 18Gbps HDMI signals up to 24.9 miles with zero latency for professional AV, broadcast, and installation workflows.
Built for long-distance 4K HDMI over fiber transmission, this extender set is a strong fit for control rooms, live event systems, houses of worship, education spaces, command centers, and video distribution installations. It supports HDCP 2.2, HDMI loop-out, audio separation, ARC back to the transmitter, and 10G Ethernet support, giving integrators a flexible platform for high-resolution signal routing.
The CMX-FMCH002 uses single mode fiber with LC connectivity and SFP+ optical modules for reliable point-to-point extension. Bi-directional IR pass-back supports 20-60kHz IR devices, while RS-232 passthrough and command control support system integration. Its audio compatibility includes LPCM 7.1, DTS-HD, Dolby TrueHD, Dolby Digital Plus, Dolby Digital, and Dolby Atmos formats.
Key Features
- Extends HDMI 2.0 signals up to 24.9 miles over single mode LC fiber
- Supports 4K@60Hz 4:4:4 HDR10 with 18Gbps bandwidth
- Provides zero-latency uncompressed signal transmission for real-time video workflows
- Supports HDCP 2.2 for protected HDMI content compatibility
- Includes HDMI loop-out and audio separation for flexible local monitoring and audio routing
- Supports ARC back to the transmitter for return audio workflows
- Bi-directional IR pass-back supports 20-60kHz IR devices
- RS-232 passthrough and command control support integrated AV system operation
- Black powder-coated steel cabinet with venting for professional installation use
Technical Specifications
Model: CMX-FMCH002
Product Type: 4K/2K HDMI 2.0 Over Fiber Extender Set
HDMI Bandwidth: 18Gbps
HDCP Support: HDCP 2.2
Transmission Distance: ≤24.9 mi
Fiber Type: Single Mode
Fiber Connector: LC
SFP+ Optical Fiber Module Wavelengths: 1270nm (T), 1330nm (R)
Bi-Directional IR: Supports bi-directional IR pass-back and 20-60kHz IR devices
Audio Format: LPCM 7.1, DTS-HD, DTS-Audio, Dolby Digital Plus, Dolby TrueHD, Dolby Digital, Dolby Atmos
ARC: Supports ARC back to transmitter
RS-232: Supports RS-232 passthrough and command control
Cabinet: Vented black powder-coated steel cabinet
Supported Resolutions
720P: 50/60 Hz
1080P: 24/25/50/60 Hz
1080i: 50/60 Hz
1024 x 768: 60 Hz
1280 x 768: 60 Hz
1280 x 800: 60 Hz
1280 x 960: 60 Hz
1280 x 1024: 60 Hz
1440 x 900: 60 Hz
1400 x 1050: 60 Hz
1600 x 900: 60 Hz
1600 x 1200: 60 Hz
1680 x 1050: 60 Hz
1920 x 1080: 60 Hz
1920 x 1200: 60 Hz
2560 x 1440: 60 Hz
2560 x 1600: 60 Hz
3840 x 2160: 24/25/30/50/60/23.9/29.9/59.9 Hz
4096 x 2160: 24/25/30/50/60/23.9/29.9/59.9 Hz
