Delvcam DELV-HSW5-CC 1920x1080 HD 5.5 inch Camera Top LCD Video Monitor

In a perfect union of technology and the senses, Delvcam introduces the DELV-HSW5-CC. A field monitor that not only offers full HD 1920 x 1080 resolution luminary eye candy but delivers pixel perfect images to your world by offering a built in vectorscope, waveform and histogram. Keep your input signals in check as these scopes make it a cinch to adjust and truly monitor the primary focus of your image.

The DELV-HSW5-CC is a true "Field Monitor" in every regard! Its portable compact design, rugged metal housing and sunshade and super high 1000:1 contrast ratio make it outdoor ready for field and ENG production.

In addition to all of these great features, the DELV-HSW5-CC boasts an I/O interface that accepts and converts both HDMI and 3G-SDI and can be cross-converted on the output. All wrapped up in a sturdy frame that easily mounts on top of your camera, Delvcam sets the bar high and keeps the price point low! Designed for the real heroes of our industry; the camera operators, directors, and cinematographers.

Key Features

• High Resolution: 1920 x 1080
• High Contrast: 1000:1
• 160 deg Wide Viewing Angles
• SDI and HDMI Cross Conversion Output
• Waveform, Vectorscope, and Time Code Displays
• Audio Level Meter, Histogram, and Waveform
• Right Channel Speaker and Stereo Earphone Jack
• Two User Definable Buttons
• Rugged Metal Housing

Technical Specifications

Display Screen
5.5 inch, IPS
Aspect Ratio
16:9
Brightness
450cd/m2
Input
1 3G-SDI, 1 HDMI
Output
1 3G-SDI, 1 HDMI
Current
1A
Power Consumption
12W
Input Voltage
7-24VDC
Audio
1 Speaker, 1 Earphone Jack
Weight
0.71 lb / 320g, 0.75 lb /340g (with case)
Dimensions
6.1 x 3.54 x 0.79in / 154.5x90x20mmm, 6.2 x 3.7 x 0.91in / 157.5x93x23mm (with case)
