Digital Forecast Bridge 1000 SD6 3G/HD/SD SDI and ASI Video D/A with Reclocking
Bridge1000_ SD6 is a device to distribute the signal of SDI SMPTE standard. In response to the SDI input of one, and the SDI output of six, it supports up to 1080P60 format. In addition, re-clocker and equlizer has a built-in inside, you will be able to use as a signal repeater.
Key Features
- HD/SDI distribution amplifier
- Inside cable equalizer & re-clocker
- Up to 100m (HD grade) , Up to 60m (3G grade)
- 1 HD/SDI input ( SD/HD/3G ) / ASI
- 6 HD-SDI out ( SD/HD/3G ) / ASI
- 12V DC Power supply (Operational Voltage Range : 7 ~ 17V DC)
Technical Specifications
Dimension (W x H x D)
106 x 96 x 25 (mm)
Weight
195 g
Power Level
12 VDC
Power Consumption
3.0Watts (Max : 4Watts)
Operating Temperature
-20 ~ 70
Humidity
0 to 95% RH, non-condensing
