Episode SIG-36 Signature 3 In-Ceiling Speaker, 6-Inch, Singular

Episode SIG-36 Signature 3 In-Ceiling Speaker, 6-Inch, Singular

The Episode SIG-36-IC Signature 3 6-inch in-ceiling speaker is an architectural speaker for distributed audio, media rooms, and everyday listening spaces. It combines an injection-molded polypropylene woofer, adjustable silk dome tweeter, 8-ohm impedance, and wide 110-degree listening angle for clean, balanced ceiling-mounted sound.

Built for residential AV installers and whole-home audio systems, this 6-inch in-ceiling speaker fits kitchens, living rooms, hallways, offices, and multi-zone audio projects. Choose it for a Signature 3 in-ceiling speaker installation when you need dependable performance, a flush-mount look, and flexible one-step or two-step installation.

Signature by Episode focuses on low distortion, wide dispersion, and flat frequency response for comfortable long-session listening. Push Lock by Swarm technology, gold-plated push terminals, Control4 compatibility, and optional backbox support help integrators complete clean, secure, professional speaker installations.

Key Features

• 6-Inch In-Ceiling Design: Installs into ceilings for discreet architectural audio in residential and commercial spaces.
• Polypropylene Woofer: Uses a 6-inch injection-molded polypropylene cone woofer for smooth mids and punchy bass.
• Adjustable Silk Dome Tweeter: Directs high frequencies toward the listening area for clearer, more focused sound.
• Push Lock by Swarm: Secures the speaker with a tool-free mounting system designed for faster installation.
• Flexible Install Process: Supports one-step or two-step installation to match different jobsite workflows.
• Wide Listening Angle: Provides 110-degree coverage to help reduce hot spots across the room.
• Gold-Plated Push Terminals: Creates a reliable speaker-wire connection for installed audio systems.
• Flush-Mount Design: Delivers a low-profile ceiling appearance for clean finished installations.

Technical Specifications

• Brand: Episode
• Model: SIG-36-IC
• ADI Part Number: 8P-SIG36IC
• Product Line: Architectural
• Product Series: Signature 3
• Product Type: In-ceiling speaker
• Speaker Size: 6"
• Woofer: 6" injection-molded polypropylene cone woofer
• Tweeter: 0.75" adjustable silk dome tweeter
• Connector Type: Gold-plated push terminals
• Frequency Response: 43Hz - 20kHz
• Crossover Frequency: 2.5kHz
• Nominal Impedance: 8 ohms
• Power Peak: 130W
• Sensitivity: 89dB
• Listening Angle: 110°
• Mounting Depth: 4.8"
• Mounting Depth with Enclosure: 6.2"
• Finished Dimension with Grille: 9.6"
• Cutout Diameter: 8.3"
• Dog Ear Clamping Range: 0.375" to double 0.5" substrate
• Optimal Air Volume Behind Speaker: 15 - 20 liters
• Dimensions: 9.6" W x 9.6" H x 4.8" D
• Weight: 4.6 lbs
• Compatibility: Control4
