Event Lighting HYBRICK-FX IP65 RGB LED Effect Light with Electronic Frost

Event Lighting HYBRICK-FX IP65 LED Effect Light with Pixel Control

The Event Lighting HYBRICK-FX is a powerful IP65-rated LED effect fixture designed for concerts, touring productions, stage lighting, and large-scale visual installations. Combining high-density RGB pixel effects with warm white beam lighting, this fixture delivers vibrant color animations, dynamic strobe effects, and powerful audience-impact lighting.

The fixture integrates 432 RGB LEDs arranged across segmented pixel zones along with 84 high-output warm white LEDs. This hybrid lighting system allows designers to create colorful pixel animations while simultaneously producing intense white beam effects for punchy stage highlights.

Advanced segmented pixel control enables detailed visual programming with 48 RGB pixel cells and 12 warm white beam cells. Lighting designers can generate complex chases, wave effects, and animated patterns across the fixture for immersive stage visuals.

An integrated electronic frost system allows users to smoothly adjust beam diffusion from a sharp, defined look to a softer wash effect without needing external filters. Built with a rugged aluminum housing and IP65 protection, the HYBRICK-FX performs reliably in both indoor and outdoor environments.

The modular interlocking housing system allows multiple fixtures to connect seamlessly for horizontal or vertical arrays, making it ideal for touring rigs, stage backdrops, and architectural lighting installations.

Key Features

• Hybrid Pixel Effect Fixture: Combines RGB pixel effects with warm white beam lighting for versatile stage visuals.
• High-Density LED Array: 432 RGB LEDs plus 84 warm white LEDs provide vibrant colors and powerful highlight effects.
• Advanced Pixel Mapping: Segmented RGB plate (48 cells) and white beam control (12 cells) enable dynamic animation effects.
• Electronic Frost System: Adjustable 0–100% frost allows instant transitions between sharp beams and soft diffusion.
• Multiple DMX Control Modes: Flexible channel configurations allow simple operation or detailed pixel programming.
• IP65 Weather Protection: Suitable for outdoor stage productions, festivals, and touring environments.
• Interlocking Fixture Design: Multiple units can be linked horizontally or vertically to create large lighting arrays.
• Professional Rigging Options: Double yoke design supports floor placement or hanging installations.

Technical Specifications

• Model: HYBRICK-FX
• Light Source: 432 × 1.5W RGB LEDs + 84 × 5W Warm White LEDs
• Warm White Color Temperature: 3250K
• Beam Angle: 120° (RGB) / 60° (Warm White)
• Output: 8,800 lux @ 1m / 2,205 lux @ 2m
• PWM Frequency: 4000 Hz
• LED Lifespan: 50,000 hours
• Dimming: 5 × 16-bit digital dimming curves
• Strobe: 1 – 25 Hz
• Pixel Control: RGB Plate (48 cells) + White Beam (12 cells)
• Control Modes: Static, Color Fade, Auto Program, Sound Active, Master/Slave, DMX, RDM, WDMX
• DMX Protocol: DMX512
• DMX Channel Modes: 1 / 2 / 3 / 4 / 14 / 15 / 50 / 146 / 158
• DMX Interface: 5-Pin XLR
• Software Upgrade: DMX Upgrade Support
• Input Voltage: 100–240V AC, 50/60Hz
• Power Consumption: 400W
• Power Connection: True1 Power Input / Output
• Cooling: Dual Fan Cooling
• IP Rating: IP65
• Housing Material: Aluminum
• Finish: Matte Black
• Product Dimensions: 14.7 × 7.3 × 5.8 inches
• Product Weight: 17.9 lbs

Rigging & Mounting

• Double yoke design for floor mounting or hanging installations
• Top and bottom mounting points for vertical bracket hanging
• Cam locks for 1/4-turn Omega bracket mounting
• Six coffin locks with tool-free handles for linking fixtures
• Maximum linked hanging load: 8 fixtures (approx. 143 lbs)
• Includes one Omega mounting bracket
