First Alert PROA7-FA All-in-One Touchscreen Security Panel

First Alert PROA7-FA All-in-One Touchscreen Security Panel

First Alert PROA7-FA is an all-in-one touchscreen security panel designed for residential and small business security installations. It enables integrated control of sensors, alarms, and monitoring communications for professional installers and system operators, supporting centralized security management. This makes it ideal for property protection scenarios where unified system control and monitoring are critical.

The panel integrates a touchscreen interface, controller, communicator, microphone, speakers, and internal sounder into a single unit. It supports encrypted wireless sensors through the ProSiX platform and can communicate through modular radio options including cellular and wireless modules. Remote management and diagnostics are supported through AlarmNet 360 cloud services.

This system allows installers to configure and maintain security installations while enabling end users to interact with their security system through the touchscreen interface. It supports multi-partition environments and automation scenarios involving compatible security and smart devices. The integrated platform supports centralized monitoring and security event management.

Key Features

• All-in-One System Design: Combines touchscreen display, controller, communicator, microphones, speakers, and internal sounder into a single security panel.
• ProSeries Security Platform: Designed for residential and small business installations with consistent programming and system management.
• Encrypted ProSiX Wireless Sensors: Supports secure wireless sensors with AES-128 encryption and over-the-air firmware updates.
• Modular Communication Options: Supports cellular, Wi-Fi, and Z-Wave communication modules for flexible system connectivity.
• AlarmNet 360 Cloud Management: Enables remote programming, diagnostics, firmware updates, and system monitoring.
• Partition Support: Allows configuration of multiple independent partitions for offices, retail spaces, or multi-dwelling installations.

Technical Specifications

Display
7 in diagonal LCD-backlit capacitive touchscreen
1024 x 600 pixel resolution
Supports millions of colors

System Capacity
250 Security Zones
Includes ProSiX and One-Way Devices
Max of 8 Indoor Outdoor MotionViewers

User Interface
Home Screen
Security Status
Arming Option Panels
Weather
Time
Awareness Notification
Idle Screen
Quick Pull-down Voice On/Off
Chime On/Off
Brightness
Volume
Clean Screen
Battery Status
Connectivity

Partitions
4 partitions with Common-Lobby option

Arming Options
Arm Away
Arm Home
Arm Night
Arm with No Entry Delay
Instant
Quick Arm
Bypass and Arm
Arm with Silent Exit
Force Arm
Auto Arm
Arm with Quick Exit Option
Disarm via Resideo Total Connect

Events
4000 Event Log

Sounder
Max Intensity 85 dB

Dimensions
Height: 5.77 in (146.6 mm)
Width: 7.90 in (200.6 mm)
Depth: 1.06 in (26.9 mm)

Weight
2.10 lb (0.95 kg)

Power
Input 110-240 VAC 50 60 Hz
Output 9 VDC 2.5 A

Backup Battery
Lithium-ion 3.6 V 7500 mAh
24 hours of backup power
