GR Bass Groove 800 / Groove 1200 Tube Bass Amplifier Heads - 800 Watt

GR Bass Groove 800 / Groove 1200 Tube Bass Amplifier Heads

The GR Bass Groove 800 / Groove 1200 Tube Bass Amplifier Heads combine a two-tube 12AX7 preamp with lightweight high-output bass amplification. Choose the Groove 800 for 800W RMS at 4 ohms or the Groove 1200 for 1200W RMS at 4 ohms, giving working bassists two power levels on the same Groove platform.

Both versions provide a four-band equalizer with switchable mid frequencies, plus Deep, Bright, Tone, and Pure functions for shaping different instruments, cabinets, and rooms. The Drive control adjusts distortion generated by the tube stage, while Pure bypasses the preamp equalization filters for a flat EQ path. A front auxiliary input, headphone monitoring, effects loop, and balanced DI support rehearsal, stage, and recording workflows.

The shared chassis also includes two combination speaker outputs with a 2.7-ohm minimum load, a rear XLR auxiliary input dedicated to headphone monitoring, footswitch control for Mute and Drive, and a 24-LED VU meter. Selectable Live and Studio fan behavior accommodates stage use and quieter recording environments, while automatic 115V/230V mains recognition simplifies operation across compatible power systems.

Key Features

• Two Power Variants: Choose 800W RMS or 1200W RMS output at 4 ohms on the shared Groove amplifier platform.
• Dual 12AX7 Tube Preamp: Two vacuum tubes provide an adjustable Drive stage for adding tube-generated harmonic character.
• Four-Band EQ: Low, Mid-Low, Mid-High, and High controls provide detailed tone shaping for different bass rigs.
• Selectable Mid Frequencies: Mid-Low switches between 220Hz and 620Hz, while Mid-High switches between 720Hz and 1750Hz.
• Pure EQ Bypass: Bypasses the preamp equalization filters when a flat EQ path is preferred.
• Professional DI Routing: Balanced XLR direct output includes independent level, pre/post EQ selection, ground lift, and anti-bump circuitry.
• Flexible Monitoring: Separate headphone level, front Aux-In, and rear XLR Aux-In support personal monitoring and playback sources.
• Live and Studio Cooling: Selectable fan modes accommodate performance use or quieter studio operation.

Technical Specifications

Variant Options

• Groove 800: 800W RMS at 4 ohms
• Groove 1200: 1200W RMS at 4 ohms

Shared Amplifier Features

• Product Type: Bass Amplifier Head
• Preamp: 2 x 12AX7 tubes
• Minimum Speaker Load: 2.7 ohms
• Equalizer: 4-band
• EQ Controls: Low, Mid-Low, Mid-High, High
• Mid-Low Frequencies: 220Hz / 620Hz
• Mid-High Frequencies: 720Hz / 1750Hz
• Tone Filter: Mid-scoop EQ
• Deep Filter: Yes
• Bright Filter: Yes
• Pure Function: Bypasses preamp equalization filters
• Drive: Adjustable tube distortion control
• Gain: Input gain control
• Master: Master output level control
• Mute: Yes
• VU Meter: 24-LED meter with multiple display modes
• Cooling Modes: Live and Studio
• Color: Black with brushed aluminum front panel

Inputs and Outputs

• Instrument Input: 1/4"
• Front Auxiliary Input: 3.5 mm
• Rear Auxiliary Input: XLR, routed to headphone output
• Headphone Output: 3.5 mm with independent level control
• DI Output: Balanced XLR with anti-bump circuitry
• DI Level: Independent control
• DI Routing: Pre/Post EQ selectable
• Ground Lift: Yes
• Effects Send: 1/4"
• Effects Return: 1/4"
• Speaker Outputs: 2 x combination speaker outputs
• Speaker Connector Support: 2-pole Speakon or 1/4"
• Footswitch Input: Mute and Drive control
• Accessory Power Output: 9V DC, center-negative
• AC Input: 115V / 230V automatic recognition

Groove 800 Performance

• Power Output: 800W RMS at 4 ohms
• Dynamic Range: 117 dBA
• THD+N: 0.005% at 1W into 4 ohms at 1kHz; 0.0008% at 50W into 4 ohms at 100Hz
• Output Impedance: 6 mOhm
• Total Efficiency: 84% at 800W into 4 ohms
• Dimensions: 13.4" W x 10.2" D x 2.8" H
• Weight: 7.5 lb

Groove 1200 Performance

• Power Output: 1200W RMS at 4 ohms
• Dynamic Range: 123 dBA
• THD+N: 0.003% at 50W into 4 ohms at 1kHz; less than 0.002% at 100W into 4 ohms at 100Hz
• Output Impedance: 6 mOhm
• Total Efficiency: 80% at 1200W into 4 ohms
• Dimensions: 13.4" W x 10.2" D x 2.8" H
• Weight: 7.9 lb

What's In the Box

• GR Bass Groove 800 or Groove 1200 Bass Amplifier Head
• Power Supply Cable
