Hollyland Astra P1 4K60 NDI HX3 30x Zoom PTZ Camera

Hollyland Astra P1 4K60 NDI HX3 30x Zoom PTZ Camera

The Hollyland Astra P1 4K60 NDI HX3 30x Optical Zoom PTZ Camera is a professional pan-tilt-zoom camera for live production, worship, halls, auditoriums, and event streaming. It combines UHD 4K60 imaging, a 1/1.8" CMOS sensor, AI auto tracking, face-detection auto exposure, and flexible broadcast connectivity.

Built for production teams that need clean coverage with fewer operators, the Astra P1 supports presenter tracking and zone tracking for large spaces. It is a strong choice for buyers looking for a 4K PTZ camera for church streaming, an NDI HX3 PTZ camera, or a 30x optical zoom camera for live events.

The Astra P1 integrates into modern video workflows with HDMI 2.0, 3G-SDI, USB, LAN, RS232, RS485, and PoE+ support. It delivers up to three independent HD streams and supports professional protocols including NDI|HX3, RTSP, RTMP(S), SRT, VISCA, Pelco, USB UVC, and FreeD.

Key Features

• UHD 4K60 Imaging: Captures detailed 4K video at up to 60 fps for professional live production and streaming workflows.
• 30x Optical Zoom: Moves from wide shots to close-ups with a 7.1mm to 210mm optical zoom range.
• AI Auto Tracking: Tracks presenters using human-based logic and supports zone tracking across up to four defined areas.
• Face Detection AE: Adjusts exposure around the subject’s face to maintain visibility in changing lighting conditions.
• NDI HX3 Support: Integrates with IP-based production systems for high-quality low-latency video over Ethernet.
• Single-Cable PoE+ Workflow: Supports video, audio, power, and control over one Ethernet cable when used with PoE+ infrastructure.
• Broadcast-Grade I/O: Provides HDMI 2.0, 3G-SDI, USB, LAN, RS232, RS485, line input, and line output connections.
• Preset PTZ Control: Stores up to 255 preset positions with 0.1° accuracy for repeatable camera moves.

Technical Specifications

• Brand: Hollyland
• Model: Astra P1
• Product Type: Pan-tilt-zoom camera
• Color: Black
• Image Sensor: 1/1.8" high-quality CMOS sensor
• Effective Pixels: 8.42 megapixels, 16:9 aspect ratio
• Maximum Video Resolution: UHD 4K60
• Optical Zoom: 30x, f = 7.1mm to 210mm
• Digital Zoom: 16x
• Aperture Range: F1.61 to F5.19
• Field of View: Horizontal 59.2° to 2.5°; vertical 34.6° to 1.4°
• Minimum Illumination: 0.5 lux, F1.8, AGC on
• Shutter Speed: 1/30s to 1/10000s
• Signal-to-Noise Ratio: ≥55dB
• HDMI Video Formats: 2160p25/29.97/30/50/59.94/60; 1080p29.97/30/50/59.94/60; 1080i50/59.94/60; 720p59.94/60
• 3G-SDI Video Formats: 1080p25/29.97/30/50/59.94/60; 1080i50/59.94/60; 720p59.94/60
• Pan Range: ±170°
• Tilt Range: -30° to +90°
• Pan Speed: 1.7°/s to 100°/s
• Tilt Speed: 1.7°/s to 69.9°/s
• Preset Positions: 255 positions with 0.1° accuracy
• Audio I/O: 1 x 3.5mm line input, 1 x 3.5mm line output
• Control Interfaces: 1 x RS485 2-pin Phoenix terminal, 1 x RS232 IN 8-pin Mini-DIN
• Network Interface: 1 x RJ45 10M/100M/1000M adaptive Ethernet
• USB Interfaces: 1 x USB 2.0 Type-A, 1 x USB 3.0 Type-B
• Video Outputs: 1 x 3G-SDI, 1 x HDMI 2.0
• Video Compression: H.264, H.265, MJPEG
• Video Streams: Main stream and sub stream
• Main Stream Resolutions: 3840 x 2160, 1920 x 1080, 1280 x 720, 1024 x 576, 720 x 480, 720 x 408, 640 x 480, 640 x 360
• Sub Stream Resolutions: 720 x 480, 720 x 408, 640 x 480, 640 x 360, 480 x 320, 320 x 240
• Supported Protocols: NDI|HX3, TCP/IP, HTTP, RTSP, RTMP(S), DHCP, SRT, Multicast, VISCA, Pelco, USB UVC, and FreeD
• Input Voltage: DC 12V / PoE+
• Input Current: 2A max.
• Power Consumption: 18W max.
• Operating Temperature: 32°F to 104°F
• Storage Temperature: -40°F to 140°F
• Dimensions: 6.65" x 7.40" x 8.90"
• Net Weight: 5.07 lbs
• UPC: 191460010484

What's Included

• Hollyland Astra P1 PTZ Camera
• Remote Controller
• Power Adapter
• USB-B to USB-A Cable
• RS232 Cable
• Wall Mount Bracket
• Ceiling Mount Bracket
