At launch, the Hollyland Pyro H USB-C 4K HDMI Wireless Video Receiver automatically selects a high-quality frequency channel, enhancing the user experience from the start. Moreover, users can engage the smart channel scan feature on the receiver to monitor real-time feedback on frequency status, ensuring a smooth and uninterrupted experience.

UVC technology enables seamless compatibility with a wide array of devices, like computers, without the need for capture cards or software installations. This plug-and-play feature simplifies setup and operation, offering convenience to users in various scenarios such as live streaming and video conferencing.

Pyro H facilitates preset grouping and pairing, eliminating the necessity for users to repeatedly set up the transmitter and receivers manually. Efficiency is crucial for team members.

Aside from DC and NP-F batteries, Pyro H also supports a USB-C power supply (5-12V). This power supply option proves advantageous, particularly when using stabilizers, as it removes the reliance on NP-F batteries, reducing overall weight and improving maneuverability.

Key Features

• Receiver Only

• Various power supply options include DC (locking), NP-F battery, and USB-C (Charging via USB-C at a minimum of 5V/2A will restart the device; this power supply option is not supported in Broadcast mode).

• The receiver supports USB Video Class (UVC).

• Input: 2.0mm Core Socket for DC power

• HDMI Loopout: HDMI 1.4b for video output

• USB-C: USB 2.0 OTG for versatile connectivity

• Antenna: SMA Male for wireless signal reception

• 5 GHz Frequency Band: 5.150 5.250 GHz, 5.250 5.350 GHz, 5.470 5.725 GHz, 5.725 5.850 GHz for high-speed wireless communication

• 2.4 GHz Frequency Band: 2.412 2.484 GHz for reliable wireless connectivity.

Technical Specifications

Receiver
Port
DC Input
2.0mm Core Socket
HDMI Loopout
HDMI 1.4b
USB-C
USB 2.0 OTG
Antenna
SMA Male
Power Supply
USB-C
5V/2A (not supported in Broadcast mode)
Battery Voltage Range
6.8 - 8.4V
DC Voltage Range
6 - 16V
Power Consumption
< 4W
Net Weight
192g
Dimensions
L x W x H
109 x 62.3 x 33.4mm (4.3 x 2.45 x 1.3in.)
Input/Output Format
HDMI
720p50/60
1080i50/60
1080p24/25/30
1080p50/60
4K30/25/24
Operating Frequency
5 GHz Frequency Band
5.150 - 5.250 GHz
5.250 - 5.350 GHz
5.470 - 5.725 GHz
5.725 - 5.850 GHz
2.4 GHz Frequency Band
2.412 - 2.484 GHz
Receiver Sensitivity
-85 dBm (Broadcast: -80 dBm)
Latency
0.06s (test data when 1080p60 signals are transmitted in a laboratory)
Range
1,300ft (400m) (test data in an open, interference-free environment)
Bandwidth
20 MHz (Broadcast: 40 MHz)
