IC Realtime IPEG-D40F-IRW3 4MP Vandal-Proof IP Dome Camera

IC Realtime IPEG-D40F-IRW3 4MP Vandal-Proof IP Dome Camera with Smart IR & Perimeter Protection

The IC Realtime IPEG-D40F-IRW3 is a compact 4MP vandal-proof dome camera engineered for demanding indoor and outdoor surveillance environments. Its IK10 impact rating and IP67 weatherproof metal housing make it purpose-built for high-risk or exposed locations where standard cameras fall short — delivering reliable 4MP clarity at 30fps around the clock.

Security integrators and facility managers searching for the best 4MP vandal-proof IP dome camera for outdoor use will find the IPEG-D40F-IRW3 strikes a powerful balance of intelligence and durability. Smart IR with up to 98 feet of infrared range handles complete darkness, while 120dB Wide Dynamic Range (WDR) and Backlight Compensation eliminate washout in high-contrast lighting — common challenges at building entrances, parking structures, and retail environments. Its PoE or 12VDC power flexibility simplifies installation across virtually any existing infrastructure.

Part of the IC Realtime Edge lineup, the IPEG-D40F-IRW3 supports ONVIF Profile S/G/T interoperability for seamless integration with third-party NVR platforms, while native pairing with IC Realtime NVRs unlocks advanced intelligent search and incident review workflows. H.265 Smart compression dramatically reduces bandwidth and storage demands without sacrificing image quality — a critical advantage for multi-camera deployments. The camera is backed by a 7-year warranty and U.S.-based technical support, underscoring IC Realtime's commitment to professional-grade reliability.

Key Features of the IC Realtime IPEG-D40F-IRW3 IP Dome Camera

• IK10 Vandal Resistance & IP67 Weatherproofing: Metal construction rated to withstand deliberate physical impact and complete water ingress protection — engineered for exposed, high-risk, and outdoor installations.
• 4MP Resolution at 30fps: Captures sharp 2688×1520 video at a smooth 30 frames per second, delivering the detail needed to identify faces, license plates, and activity across a wide scene.
• Smart IR with 98-Foot Illumination Range: Three IR LEDs with automatic intensity control eliminate overexposure at close range while maintaining visibility out to 98 feet — ensuring clear footage in total darkness.
• AI-Powered Perimeter Protection: Intelligent tripwire and intrusion detection with human/vehicle classification reduces false alerts from environmental triggers and enables faster, more accurate incident review when paired with an IC Realtime NVR.
• 120dB WDR & Backlight Compensation: Handles extreme contrast scenarios — direct sunlight, headlights, and shadowed areas — that challenge standard cameras, maintaining usable image detail across the full frame.
• Built-In Microphone & 256GB MicroSD Support: Onboard audio capture and local edge storage up to 256GB provide complete recording redundancy independent of network availability.
• Flexible Power & Broad Compatibility: Supports PoE (802.3af) and 12VDC power inputs; ONVIF Profile S/G/T compliant; integrates with IC Now desktop platform and IC View+ mobile app for iOS and Android remote monitoring.

Technical Specifications

• Image Sensor: 1/2.9" CMOS
• Effective Pixels: 2688 (H) × 1520 (V)
• RAM / ROM: 128 MB / 128 MB
• Scanning System: Progressive
• Minimum Illumination: 0.006 lux @ F1.6 (Color, 30 IRE); 0.0006 lux @ F1.6 (B/W, 30 IRE); 0 lux (IR on)
• IR Illumination Distance: 98.43 ft (30 m)
• IR LEDs: 3
• Illumination Control: Auto / Manual
• Lens Type: Fixed-focal, M12 mount
• Focal Length: 2.8 mm
• Maximum Aperture: F1.6
• Angle of View: Horizontal 102°; Vertical 54°
• Close Focus Distance: 2.3 ft (0.7 m)
• DORI — Detect: 208 ft
• DORI — Observe: 83 ft
• DORI — Recognize: 41 ft
• DORI — Identify: 21 ft
• Video Compression: H.265; Smart H.265+; H.264; Smart H.264+; H.264H; H.264B; MJPEG (sub stream only)
• Main Stream Resolution: Up to 4MP (2688×1520) @ 20fps; 2560×1440 @ 25/30fps
• Sub Stream Resolution: 704×576 @ 25fps; 704×480 @ 30fps
• Bit Rate: H.264: 32–6144 kbps; H.265: 12–6144 kbps
• Bit Rate Control: CBR / VBR
• Day/Night Mode: Auto (ICR) / Color / B&W
• Wide Dynamic Range: 120dB WDR
• Backlight Compensation: BLC, HLC, WDR
• White Balance: Auto; Natural; Street Lamp; Outdoor; Manual; Regional Custom
• Noise Reduction: Auto / Manual
• Smart IR: Supported
• Image Flip / Mirror: 0° / 90° / 180° / 270° flip; Mirror supported
• Privacy Masking: Up to 4 areas
• Intelligent Functions: Perimeter Protection (Tripwire, Intrusion — human/vehicle classification); Intelligent Motion Detection
• Audio Compression: G.711a; G.711Mu; G.726; PCM
• Audio Input: Built-in microphone
• Network Interface: RJ-45 (10/100 Base-T)
• Supported Protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
• Interoperability: ONVIF Profile S / Profile G / Profile T; CGI
• Maximum Simultaneous Users: 6 (total bandwidth: 36 Mbps)
• Edge Storage: MicroSD up to 256 GB; FTP; SFTP
• Web Browser Support: IE, Chrome, Firefox, Safari
• Management Software: IC Now; IC Now Pro
• Mobile App: IC View+ (iOS and Android)
• Power Supply: 12VDC / PoE
• Power Consumption: Basic: 2.3W (12VDC) / 2.9W (PoE); Max: 5W (12VDC) / 6W (PoE)
• Operating Temperature: -40°F to +140°F (-40°C to +60°C)
• Operating Humidity: ≤95% RH (non-condensing)
• Enclosure Rating: IP67 / IK10
• Casing Material: Metal
• Pan / Tilt / Rotation: Pan 0°–355°; Tilt 0°–65°; Rotation 0°–355°
• Dimensions: 3.19" (H) × Ø4.33" (81.0 mm × Ø109.9 mm)
• Gross Weight: 1.08 lb (0.49 kg)
• Warranty: 7 Years
