JBL Control 414C/T 4-Inch 2-Way Coaxial Ceiling Loudspeaker 70V/100V (Pair)

JBL Control 414C/T 4-Inch 2-Way Coaxial Ceiling Loudspeaker

The JBL Control 414C/T is a 4-inch two-way coaxial ceiling loudspeaker from the Control 400 Standard Coverage Series, delivering 65 Hz to 20 kHz frequency response with combined 70V/100V and low-impedance operation in a standard-depth plenum enclosure - replacing the legacy Control 14C/T with improved installation features and modern aesthetics.

Designed for retail stores, corporate offices, education facilities, and hospitality environments, the Control 414C/T handles both background music and speech paging with consistent clarity. Its 8-ohm direct impedance allows up to two speakers per 4-ohm amplifier channel, while the built-in multi-tap transformer enables flexible distributed audio system wiring without additional components.

All Control 400 Series models are engineered with installer-friendly features: terminal covers with top and side cable entry, captive hand-screws for tool-free securing, and a captive dogear mounting system compatible with a wide range of ceiling thicknesses. The full-face magnetic grille is paintable and includes an integrated safety tether, meeting UL 1480A, UL 2043, NFPA 90A, and NFPA 70 requirements for plenum-rated installations.

Key Features

• 4-Inch Two-Way Coaxial Driver: Coaxially mounted 100mm woofer and 20mm soft-dome tweeter deliver wide-bandwidth performance from a compact ceiling profile.
• Combined 70V/100V and Direct Operation: Integrated multi-tap transformer with 8-ohm direct input supports both distributed and low-impedance system architectures from a single speaker.
• 65 Hz to 20 kHz Response: Full-range frequency coverage handles background music, speech paging, and announcement systems with equal clarity.
• Paintable Magnetic Grille: Full-face, bezel-less magnetic grille with safety tether accepts standard paint for seamless ceiling integration.
• Captive Dogear Mounting: Reliable captive dogear design accommodates a wide range of ceiling thicknesses for consistent, repeatable installation.
• Plenum-Rated: UL 1480A and UL 2043 listed for safe operation in air-handling ceiling plenum spaces.

Technical Specifications

• LF Driver: 100 mm (4 in) woofer
• HF Driver: 20 mm (0.75 in) soft-dome tweeter
• Frequency Range: 65 Hz - 20 kHz
• Transformer: 70V/100V multi-tap
• Impedance (Direct): 8 ohm
• Sold As: Pair
• Dimensions (H x Dia.): 7.4 in (186 mm) H x 8.1 in (203 mm) dia.
• IP Rating: IP33 per EN/IEC 60529
• Safety Certifications: UL 1480A, UL 2043, NFPA 90A, NFPA 70, CSA C22.2 No. 205
• Operating Temperature: 0 deg C to 45 deg C

What's Included

• (2) JBL Control 414C/T Ceiling Loudspeakers
• Mounting Hardware
• White Round Paintable Magnetic Grilles
