JBL CONTROL 50S/T Surface Mount Subwoofer for Subwoofer Satellite Loudspeaker System Pair

JBL CONTROL 50S/T | Surface Mount Subwoofer for Subwoofer Satellite Loudspeaker System Pair

Unleash the power of dynamic, full-range sound with the JBL CONTROL 50S/T Surface Mount Subwoofer. Specially designed for Subwoofer Satellite Loudspeaker Systems, this robust speaker is ideal for commercial and professional audio environments. The Control 50S/T subwoofer integrates a high-power, long-excursion 200 mm (8 inch) driver, capable of delivering 150 Watts of continuous power and up to an impressive 600 Watts of peak power. Engineered for optimal performance, the subwoofer features a high-mass cone ensuring extended low-frequency response, alongside a 4-layer copper voice coil for robust motor strength. Rubber half roll surrounds provide enhanced bass performance, making this subwoofer an essential component for complete sound systems.

Whether you're setting up in a restaurant, retail space, conference room, or any environment requiring superior audio delivery, the JBL CONTROL 50S/T offers unmatched versatility. It operates with selectable 70V/100V for distributed lines, or low impedance, capturing a full bandwidth of 32 Hz – 20 kHz. Its nominal impedance is set at 8 ohms, allowing it to seamlessly integrate with two or four satellite speakers per system. Available in both black and white finishes, the JBL CONTROL 50S/T not only delivers outstanding audio but does so with style.

Constructed with top-tier materials, the unit is built to last, featuring structural plywood for the body and a painted zinc-plated metal grille. It also includes practical accessories for easy installation, making this an all-in-one solution for your sound system needs.

Key Features

• Full bandwidth 32 Hz – 20 kHz high fidelity sound
• Selectable 70V/100V for distributed lines, or low impedance
• Compatible with either two or four satellite speakers per system
• Available in black or white finishes

Specifications

• Frequency Range (-10 dB): 32 Hz – 200 Hz
• Frequency Response (±3 dB): 50 Hz – 150 Hz
• Power Capacity: 300 Watts Continuous Program Power (2 hrs), 150 Watts Continuous Pink Noise (2 hrs), 200 Watts Continuous Program Power (100 hrs), 100 Watts Continuous Pink Noise (100 hrs)
• Nominal Sensitivity (2.83V, 1m): 95 dB (near corner), 89 dB (center of wall)
• Rated Maximum SPL (1m): 115 dB average, 121 dB peak (near corner), 109 dB average, 115 dB peak (center of wall)
• Nominal Impedance: 8 ohms (in bypass/thru mode)
• Transformer Taps: 80W, 40W, 20W (10W @ 70V), 8 ohm bypass/thru
• Transducer Driver: 200 mm (8 inch) with polypropylene cone, butyl rubber surround, 38 mm (1.5 inch) 4-layer copper-clad coil, vented aluminum former
• Input Connectors: Six removable locking 2-pin connectors with screw-down terminals, Max wire 12 AWG (2.5 mm²)
• Material: Top, bottom, front & bottom - Structural plywood; Port & terminal panels - MDF; Grille - Painted zinc-plated metal
• Dimensions (H x W x D): Cabinet - 356 x 391 x 203 mm (14.0 x 15.4 x 8.0 inches); Wall Bracket - 15 mm (0.6 inches) deep, 2.3 mm (0.9 inches) thick zinc-plated and painted cold-rolled steel
• Net Weight: 9.0 kg (20 lbs)
• Shipping Weight: 10.2 kg (23 lbs)

Package Contents

• Wall bracket (both speaker and wall parts) with 4 pcs M6 screws to attach to speaker
• Terminal cover
• 6 pcs 2-pin locking connectors
• M6 screw for safety lanyard attachment
