LaCie STNC256000400 8big Pro5 256TB 8-Bay Thunderbolt 5 RAID Array

Post houses, VFX facilities and high-volume content teams that need a quarter-petabyte on the desk can start with the LaCie 8big Pro5 STNC256000400. This top-capacity configuration ships with eight 32TB SATA hard drives installed for 256TB of raw storage in an eight-bay desktop chassis, connected to the host over a single Thunderbolt 5 cable.

Thunderbolt 5 bandwidth up to 120Gbps lets the array sustain up to 2,800 MB/s in RAID 0 and up to 2,500 MB/s in RAID 5, so editors and colorists can work directly from the array on 8K and high-bitrate footage. Hardware RAID supports levels 0, 1, 5, 6, 10, 50, 60 and JBOD, letting a studio choose its own balance of speed and redundancy, and the host port supplies up to 140W to power a connected laptop.

Two downstream Thunderbolt 5 ports and a 20Gbps USB-C port allow displays and peripherals to be daisy-chained from the array. It works with macOS and Windows and is covered by a five-year limited warranty with Rescue Data Recovery Services.

Features

• 256TB installed: eight 32TB SATA hard drives in an eight-bay desktop chassis
• Thunderbolt 5 host connection, up to 120Gbps
• Up to 2,800 MB/s in RAID 0 and 2,500 MB/s in RAID 5
• Hardware RAID 0, 1, 5, 6, 10, 50, 60 and JBOD
• Up to 140W power delivery to a connected laptop over the host port
• Two downstream Thunderbolt 5 ports plus a 20Gbps USB-C port
• Five-year limited warranty with Rescue Data Recovery Services

Technical Specifications

• Model: STNC256000400
• Capacity: 256TB (8 x 32TB SATA HDD)
• Bays: 8, populated
• Interface: Thunderbolt 5 (up to 120Gbps), backward compatible with Thunderbolt 4/3 and USB4
• Max transfer: up to 2,800 MB/s (RAID 0), up to 2,500 MB/s (RAID 5)
• RAID: 0, 1, 5, 6, 10, 50, 60, JBOD
• Compatibility: macOS and Windows
• Unit dimensions: 11.69 x 9.13 x 8.47 in
• Warranty: 5-year limited

What's Included

• LaCie 8big Pro5 256TB RAID array with 8 drives installed
• Thunderbolt 5 cable
• Power cable
• Quick install guide
