Miri V410 4K Live Encoder/Decoder with NDI, SRT and Wi-Fi 7

Miri V410 4K Live Encoder/Decoder with NDI, SRT and Wi-Fi 7

The Miri V410 4K Live Encoder/Decoder is a configurable hardware codec for live streaming, IP production, and AV-over-IP distribution. It encodes one 4K60 source or two QHD60 sources, decodes two 4K60 streams, and supports NDI, SRT, RTMP, HLS, RTSP, HDMI, 3G-SDI, and USB workflows.

Designed for broadcast productions, houses of worship, corporate events, education, and remote contribution, the V410 adapts to encoding or decoding requirements through a user-friendly browser interface. Independent streaming profiles enable delivery to multiple platforms, while local recording to microSD cards or USB storage creates convenient backup and archival options.

Built-in Wi-Fi 7 and dual Gigabit Ethernet ports support resilient network deployment, multi-LAN operation, and PoE installation. A 2-inch LCD, configurable shortcut buttons, VU meters, headphone monitoring, and a large tally light provide immediate front-panel feedback. API and SNMP support also help engineers integrate the unit into managed professional video systems.

Key Features

• Configurable Encoder or Decoder: Changes operating modes to support contribution, distribution, monitoring, and streaming workflows.
• Dual-Channel Processing: Encodes one 4K60 source or two QHD60 sources and decodes up to two 4K60 streams.
• Flexible Streaming Protocols: Supports SRT, RTMP, RTMPS, HLS, TS over UDP, and RTSP using H.264 or H.265 compression.
• Professional IP Video: Encodes and decodes NDI HX2 and NDI HX3 while decoding NDI High Bandwidth and OMT sources.
• Multiple Video Interfaces: Integrates HDMI 2.0, 3G-SDI, USB webcam, and network-based sources and destinations.
• Multi-Platform Streaming: Streams to as many as eight platforms using two independent encoding configurations up to 40 Mbps each.
• Wi-Fi 7 and Dual Ethernet: Provides robust wireless performance, network redundancy, multi-LAN connectivity, and PoE support.
• Local Monitoring and Recording: Includes an LCD, VU meters, headphone output, tally light, microSD recording, and external USB recording.

Technical Specifications

General

• Product Type: Configurable 4K Live Video Encoder and Decoder
• Model: V410
• Operating Modes: Encoder or Decoder
• Applications: Live Streaming, IP-Based Production, and AV-over-IP Distribution
• Front-Panel Display: 2.0" LCD
• Front-Panel Controls: Menu Buttons and Configurable Shortcut Buttons
• Monitoring: Front-Panel VU Meters, Headphone Jack, and Large Tally Light

Encoding and Transcoding Inputs

• HDMI Input: HDMI 2.0 up to 3840 x 2160 at 60 fps
• SDI Input: 3G-SDI up to 1920 x 1080 at 60 fps
• USB Webcam Input: Up to 1920 x 1080 at 30 fps
• NDI HX2 and HX3 Input: Up to 3840 x 2160 at 60 fps
• NDI High Bandwidth Input: One Source up to 1920 x 1080 at 60 fps
• Transcoding: Converts NDI High Bandwidth, NDI HX2, or NDI HX3 Sources to Supported Streaming Formats in Encode Mode

Decoding Inputs

• H.264 and H.265 Input: Up to 3840 x 2160 at 60 fps
• Streaming Input Protocols: SRT, RTMP, RTMPS, HLS, TS over UDP, and RTSP
• NDI HX2 and HX3 Input: Up to 3840 x 2160 at 60 fps
• NDI High Bandwidth Input: Up to 3840 x 2160 at 60 fps, Subject to Simultaneous Decoding Limits
• OMT Input: Supported, Subject to Simultaneous Decoding Limits

Decoding Outputs

• HDMI Output: HDMI 2.0 up to 3840 x 2160 at 60 fps
• SDI Output: 3G-SDI up to 1920 x 1080 at 60 fps
• USB Webcam Output: Up to 1920 x 1080 at 30 fps

Simultaneous Processing

• Maximum Simultaneous Encoding: One 3840 x 2160 Source at 60 fps or Two 2560 x 1440 Sources at 60 fps
• Dual 4K Decoding: Two 3840 x 2160 Sources at 60 fps for Supported Formats, with One 4K HDMI Output and One Down-Converted HD 3G-SDI Output
• Mixed NDI Decoding: One 1080p60 NDI High Bandwidth Source and One 4K60 Source in Another Supported Format
• Single NDI High Bandwidth Decoding: One 3840 x 2160 Source at 60 fps
• OMT Decoding: One OMT Source

SDI Video Resolutions

• 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, and 23.98 fps
• 1080i: 60, 59.94, and 50 fps
• 720p: 60, 59.94, and 50 fps
• PAL: 720 x 576i at 50 fps
• NTSC: 720 x 480i at 59.94 fps

HDMI Video Resolutions

• HDMI 4K Ultra HD: 3840 x 2160 at 60, 50, 30, and 25 fps
• HDMI QHD: 2560 x 1440 at 60 and 30 fps
• HDMI 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, and 23.98 fps
• HDMI 1080i Output: 60, 59.94, and 50 fps
• HDMI 720p Input: 60, 59.94, 50, 30, 29.97, and 25 fps
• HDMI 720p Output: 60, 59.94, and 50 fps

USB Webcam Resolutions

• 1080p: 30, 29.97, 25, 24, and 23.98 fps
• 720p: 30, 29.97, and 25 fps

Video and Audio Encoding

• H.264 Codec: Baseline, Main, and High Profiles; Level 5.2
• H.265 Codec: Main Profile; Level 5.1
• Audio Encoding: AAC
• Streaming Outputs: SRT, RTMP, RTMPS, HLS, TS over UDP, and RTSP
• Encoding Profiles: Two Independent Sets of Parameters up to 40 Mbps Each
• Simultaneous Streaming Destinations: Up to 8 Platforms

NDI and Graphics

• NDI Input: NDI High Bandwidth, NDI HX2, and NDI HX3
• NDI Output: NDI HX2 and NDI HX3
• NDI Bridge: Integrated
• Output Overlays: Up to 8 Text or Image Overlays

Recording and Audio Interfaces

• Recording Media: microSD/TF Card or External USB Storage
• Headphone Output: 1 x 3.5mm Front-Panel Output
• Analog Audio Input: 1 x 3.5mm Line Input
• Analog Audio Output: 1 x 3.5mm Line Output

Networking and Management

• Ethernet: 2 x 1000 Mbps RJ45 Ports
• Power over Ethernet: Supported on One Ethernet Port
• Wireless Networking: Wi-Fi 7
• Management Interface: Browser-Based Web Interface
• Scheduling: Scheduled Streaming and Recording
• Integration: API and SNMP Support

Power and Physical Specifications

• Power Supply: 12V DC, 2A
• Dimensions (W x D x H): 8.27" x 5.60" x 1.73"
• Weight: 1.88 lbs, Excluding Antennas
