MSI PRO X870E-P WIFI AMD X870E AM5 ATX Motherboard

MSI PRO X870E-P WIFI AMD X870E AM5 ATX Motherboard for Ryzen 9000

The MSI PRO X870E-P WIFI is an ATX motherboard built on the AMD X870E chipset for Socket AM5 processors, supporting AMD Ryzen 9000, 8000, and 7000 series CPUs with up to 256GB DDR5 memory, PCIe 5.0 x16, Wi-Fi 7, and 5G LAN for professionals demanding performance and reliability.

Ideal for content creators, productivity-focused professionals, and home office power users seeking a feature-rich AM5 platform, the PRO X870E-P WIFI suits builds requiring high-speed networking for remote work, multi-drive NVMe storage for video editing, and DDR5 overclocking headroom for demanding multitasking workloads.

Backed by MSI's 3-year warranty and engineered within the PRO Series lineup, this board carries MSI's reputation for business-grade quality and compatibility, supporting Windows 11 64-bit and the full AMD EXPO memory overclocking ecosystem.

Key Features of the MSI PRO X870E-P WIFI

• Wi-Fi 7 with EZ Antenna: Tri-band wireless (2.4GHz / 5GHz / 6GHz) up to 5.8Gbps with MU-MIMO TX/RX and Bluetooth 5.4 for ultra-low-latency connectivity and future-proof wireless performance.
• 5G LAN (Realtek 8126VB): Onboard 5-gigabit wired Ethernet delivers fast, stable network throughput ideal for large file transfers and low-latency online collaboration.
• PCIe 5.0 M.2 with EZ M.2 Shield Frozr II: The primary M.2 slot supports PCIe 5.0 x4 speeds for next-generation NVMe SSDs, with a tool-free heatsink keeping thermals in check.
• DDR5 Memory Support up to 8200+ MT/s: Four DIMM slots support up to 256GB DDR5 with AMD EXPO overclocking profiles and Dual-Channel mode for maximum bandwidth in memory-intensive workloads.
• USB 40Gbps Type-C Rear Port: Includes USB4 (40Gbps) Type-C on the rear I/O with DisplayPort 1.4 HBR3 support, plus USB 20Gbps Type-C, USB 10Gbps, and USB 5Gbps for versatile peripheral connectivity.
• Supplemental PCIe Power Connector: An 8-pin supplemental PCIe power connector ensures stable power delivery for high-performance GPUs in demanding configurations.
• AI-Powered System Management: MSI Center integration with AI Engine, AI LAN Manager, Frozr AI Cooling, and AI Boost automatically optimizes performance, networking, and cooling for effortless system tuning.
• Elegant Silver PRO Series Design: A clean silver color scheme suits both white and black PC builds, reflecting the professional aesthetic of MSI's PRO lineup.

Technical Specifications

• Chipset: AMD X870E
• Socket: AMD AM5
• Supported CPUs: AMD Ryzen 9000, 8000, 7000 Series Desktop Processors
• Form Factor: ATX (243.84mm x 304.8mm)
• Memory Slots: 4x DDR5 UDIMM
• Max Memory: 256GB
• Memory Speed: DDR5 8200-5600 MT/s (OC) / 5600-4800 MT/s (JEDEC)
• Memory Features: Dual-Channel, AMD EXPO, Non-ECC Unbuffered, CUDIMM (Clock Driver bypass mode)
• PCIe Slots: 3x PCIe x16 + 1x PCIe x1 (PCI_E1: PCIe 5.0 x16 from CPU; PCI_E2: PCIe 3.0 x1; PCI_E3: PCIe 4.0 x4; PCI_E4: PCIe 3.0 x1)
• M.2 Slots: 3x M.2 (M.2_1: PCIe 5.0 x4 from CPU; M.2_2: PCIe 4.0 x4 from Chipset; M.2_3: PCIe 4.0 x4 from Chipset, supports 22110)
• SATA Ports: 4x SATA 6Gbps
• RAID: RAID 0, 1, 10 for SATA; RAID 0, 1, 5 for NVMe M.2
• Onboard Graphics Output: 1x HDMI 2.1 (4K 60Hz); 1x USB-C DisplayPort 1.4 (4K 60Hz via USB4)
• Audio: Realtek ALC897, 7.1-Channel High Definition Audio
• LAN: Realtek 8126VB 5G LAN
• Wireless: Wi-Fi 7 (802.11a/b/g/n/ac/ax/be), 2.4/5/6GHz (320MHz) up to 5.8Gbps, MU-MIMO TX/RX
• Bluetooth: 5.4, MLO, 4K-QAM
• Rear USB: 4x USB 2.0, 2x USB 5Gbps Type-A, 2x USB 10Gbps Type-A, 1x USB 20Gbps Type-C, 1x USB 40Gbps Type-C
• Front Panel USB: 6x USB 2.0, 4x USB 5Gbps Type-A, 1x USB 10Gbps Type-C
• Fan Headers: 1x CPU Fan, 1x Combo (Pump/Sys), 6x System Fan
• RGB Headers: 3x Addressable V2 RGB (JARGB_V2), 1x RGB (JRGB)
• Other Internal Headers: TPM 2.0 header, Chassis Intrusion, Tuning Controller (JDASH), Front Audio, EZ Conn-header
• EZ Debug LED: 4x EZ Debug LED + 1x EZ Memory Detection LED
• Operating System: Windows 11 64-bit
• Dimensions: 14 x 11 x 3 inches
• Weight: 5.5 lbs
• Warranty: 3 Years
• UPC: 824142425565
