NETGEAR M4300 8X8F Managed Switch

NETGEAR M4300 8X8F Managed Switch

The NETGEAR M4300 8X8F is a stackable, half-width, fully managed switch carrying eight 10GBase-T copper ports and eight SFP+ ports in a 16-port layout. It is built for AV-over-IP systems, server rooms, and growing network edges, where two half-width units can share a single rack space for redundant top-of-rack switching.

Virtual chassis stacking delivers non-stop forwarding with hitless failover, and distributed link aggregation adds load balancing with zero downtime. The switch ships pre-configured for out-of-box Layer 2 multicast and is SDVoE-ready, with NETGEAR IGMP Plus preventing network flooding. Security features include DHCP snooping, IP Source Guard, and DoS mitigation, while mix-and-match stacking works across 10G and 1G models using RJ45, SFP+, or DAC media.

Key Features

• Half-width 16-port fully managed switch with 8 x 10GBase-T and 8 x SFP+
• Non-stop forwarding virtual chassis with hitless failover across the stack
• Pre-configured for out-of-box Layer 2 multicast; SDVoE-ready with NETGEAR IGMP Plus
• Mix-and-match stacking across 10/40 Gigabit and 1 Gigabit models with RJ45, SFP+, or DAC
• Advanced IPv4/IPv6 security: DHCP snooping, IP Source Guard, and DoS mitigation
• Two half-width units combine in one rack space for redundant top-of-rack
• Non-blocking fabric for near-zero switch latency

Specifications

• Model Number: XSM4348FS
• 48 Ports SFP+ 1G / 10G
• 2x Shared 10Gb Copper 100M / 1G / 10G
• 2 Modular Bay with One (1) 250W Modular PSU included APS250W
• 960 Gbps Switching Fabric
• Fixed Fan Front-to-Back 42db
• Ethernet: Out-of-band 1G port (Back)
• Console: RJ45 RS232 (Back)
• Console: Mini-USB (Front)
• Storage: USB (Front)
• Single-pane-of-glass NMS300 management platform with mass-configuration support
• Dual firmware image and configuration file for updates with minimum service interruption
• Hardware Specifications
• Management Options:
