NETGEAR WAX610Y-100NAS Insight Managed WiFi 6 Outdoor Access Point
The NETGEAR WAX610Y Outdoor Access Point delivers Insight Managed WiFi 6 performance for outdoor business networks. It combines AX1800 dual-band wireless throughput, 2.5GbE PoE connectivity, IP55-rated weather resistance, mesh backhaul, and enterprise-grade security for reliable coverage in demanding commercial environments.
Use this outdoor WiFi 6 access point for schools, hotels, restaurants, conference centers, patios, courtyards, campuses, and other small to medium business spaces. It fits buyers who need to purchase a managed outdoor access point, expand business WiFi coverage, or install a PoE outdoor wireless access point with centralized cloud management.
The WAX610Y supports 802.11ax WiFi 6 on both 2.4GHz and 5GHz bands, while remaining backward compatible with earlier WiFi devices. OFDMA, bidirectional MU-MIMO, BSS Coloring, Target Wake Time, VLAN support, WPA3, captive portal, and Insight management help professional networks serve users securely and efficiently.
Insight Managed Outdoor WiFi 6 Performance
- AX1800 WiFi 6: Delivers aggregate wireless throughput up to 1.8Gbps across 2.4GHz and 5GHz bands.
- Outdoor-Rated Design: Uses P2i nano-coating and an IP55 rating for resistance to water, dust, and outdoor conditions.
- 2.5GbE PoE Port: Connects through one 100/1000/2.5GBASE-T RJ45 Ethernet port with IEEE 802.3af or 802.3at PoE.
- Dual-Band 2x2 Radio: Supports 2x2 transmit and receive operation on both 2.4GHz and 5GHz bands.
- Instant WiFi Mesh: Forms wireless backhaul with compatible NETGEAR access points for scalable mesh coverage.
- Enterprise Security: Supports WPA, WPA2, WPA3, WPA2 Enterprise, VLANs, MAC authentication, and 802.1x RADIUS.
- Guest Network Control: Provides up to eight SSIDs with captive portal, VLAN segmentation, and bandwidth management.
- Insight Management: Enables app-based setup, monitoring, and management through NETGEAR Insight.
Technical Specifications
- Product Type: Insight Managed WiFi 6 AX1800 outdoor wireless access point
- Model: WAX610Y
- North America Ordering Part Number: WAX610Y-100NAS
- WiFi Standard: IEEE 802.11ax WiFi 6
- Wireless Standards: 5GHz: 802.11a/n/ac/ax; 2.4GHz: 802.11b/g/n/ax
- Wireless Mode: 2x2 transmit and receive on 5GHz; 2x2 transmit and receive on 2.4GHz
- Maximum Theoretical Throughput: AX1800, 1.8Gbps
- Maximum Throughput Per Band: 5GHz: 1200Mbps; 2.4GHz: 600Mbps
- Antenna Gain: Internal 3.6dBi at 2.4GHz; internal 4.4dBi at 5GHz
- Maximum Users: 250
- Concurrent Users: 30
- Ideal Use: Small and medium business
- Outdoor Use: IP55 water and dust resistance for outdoor environments
- OFDMA: Yes
- OFDM: Yes
- BSS Coloring: Yes
- Multi-User MIMO: Bidirectional MU-MIMO
- Target Wake Time: Yes
- WMM Wireless Multimedia Prioritization: Yes
- Power over Ethernet: IEEE 802.3af and IEEE 802.3at
- PoE Power Consumption: 16.1W
- Ethernet Interface: 1 x 100/1000/2.5GBASE-T Gigabit Ethernet RJ45 port with Auto Uplink and Auto MDI-X
- Power Adapter: Powered by PoE only
- LED Indicators: Power and cloud connection, LAN speed, 2.4GHz status, 5GHz status
- Centralized Management: NETGEAR Insight App
- Remote Management: Insight and standalone management
- NETGEAR Insight Subscription: 1-year subscription included
- Secure Socket Layer: Yes
- Router Mode: No
- Wireless Distribution System: Yes
- Bridge Modes: Point-to-point wireless and point-to-multipoint wireless
- Repeater Mode: Yes
- Simultaneous Bridge and Wireless Client Association: Yes
- Adjustable Transmit Power Control: Yes
- Device Detection: Identifies wireless client device types on the network
- Security: WPA, WPA2, WPA3, 802.11i
- Enterprise Security: WPA2 Enterprise
- Wireless Access Control: Identifies authorized wireless network devices
- MAC Address Authentication: Yes
- MAC Address Filtering: Yes
- 802.1x RADIUS Support: EAP TLS, TTLS, PEAP
- Neighbor AP Detection: Yes
- Block SSID Broadcast: Yes
- SSID Wireless Networks: 8
- VLAN Support: Yes
- Guest Network/Captive Portal: Yes
- Bandwidth Management: Yes
- Link Layer Discovery Protocol: Yes
- Band Steering: Yes
- Instant WiFi Mesh: Wireless backhaul to form a mesh network
- Operating Temperature: 10°F to 122°F with no solar radiation
- Dimensions: 7.12" W x 12.0" D x 1.33" H
- Weight: 2.07 lbs
What's In the Box
- WAX610Y Insight Managed Outdoor Wireless Access Point
- Pole Mount Kit
- Wall/Ceiling Mount Kit
- Installation Guide
