Nux Edge Delay Guitar Effects Pedal with Phi Digital Delay, Analog Delay, and Tape Echo
Nux Edge Delay Guitar Effects Pedal with Phi Digital Delay, Analog ...
NUX Edge Delay Guitar Effects Pedal with Phi Digital Delay, Analog Delay, and Tape Echo
The edge delay provides you with 3 unique delays, each including accurate control over its sonic character and feel. Clear, studio-quality digital delays. Saturated and fluctuating sounds of tape delay machines. Warm and fuzzy analog style repeats.
The Edge delay (NDD-3) is a mini delay pedal with 3 different delay types including Phi Digital Delay, Analog Delay, and Tape Echo. You can switch delay types by pressing and holding the footswitch.
DELAY SUB-DIVISIONS WITH SMART TAP TEMPOSet the Time knob parameter to your desired sub-division, then you can engage the smart tap tempo by pressing the footswitch twice to get a dynamic sub-division tap tempo delay.
Press the footswitch once to engage/disengage the effect. Press twice, to access Smart Tap Tempo. In the meantime, the delay time is related to tap tempo and current sub-division parameter. (The FS indicator will flash as current BPM.)
Mini but mighty! It also supports Stereo input & output. (Use 1/4ā TRS cable and choose Stereo mode.)
Key Features
- 3 delay types in a mini enclosure.
- Phi Digital Delay: Musical digital delay with golden ratio 2nd repeat head.
- Analog Delay: BBD Warm sound with natural treble decay.
- Tape Echo: High-frequency saturation and low-end decay.
- Sub-division with Smart Tap Tempo. (Maximum: 1500ms)
- True-bypass or Buffer-bypass (Trails).
- Supports Stereo I/O with TRS Cable.
- Low power consumption. (Less than 100mA)
- Analog dry signal for low noise and zero latency.
Technical Specifications
Input Impedance
1M ohms
Output Impedance
10k ohms
Dynamic Range
103 dB
DSP Processing
48KHz / 32-bit
A/D D/A Sampling Rate
48KHz / 24-bit
Power
9V DC (Negative tip, Optional ACD-006A adapter)
Current Draw
less than 100mA
Dimensions
94(L)X51(W)X53(H)mm
Weight
175g
