Q-SYS NC-12x80 Network PTZ Conference Camera with 12x Optical Zoom
Authorized Dealer
Free Shipping
Estimated Shipping Widget will be displayed here!
Orders placed between Monday - Friday before
1:00 PM PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Condition: New
Description
Q-SYS NC-12x80 Network PTZ Conference Camera with 12x Optical Zoom
The Q-SYS NC-12x80 Network PTZ Conference Camera is a professional conference camera with 12x optical zoom, an 80-degree horizontal field of view, and native Q-SYS platform integration. It delivers high-quality room video over the Q-LAN network for scalable conferencing, collaboration, and multi-camera AV systems.
Designed for meeting rooms, classrooms, boardrooms, and reconfigurable collaboration spaces, the NC-12x80 helps buyers purchase a network PTZ camera for Q-SYS systems without relying on long USB cable runs. Its motorized pan, tilt, and zoom functions support larger rooms where flexible camera positioning and preset recall matter.
Power over Ethernet, 12 V local power support, HDMI output, 3G-SDI output, and configurable IP streaming make the Q-SYS NC-12x80 practical for professional AV integration. Q-SYS Designer Software, Q-SYS Reflect, image rotation, and camera imaging controls support managed deployments with white balance, focus, exposure, and network-based routing.
12x Optical Zoom PTZ Camera for Q-SYS Conferencing
- 12x Optical Zoom: Frames presenters, participants, and room details with optical clarity from across the space.
- 80-Degree Horizontal Field of View: Captures wider meeting-room layouts while maintaining flexible PTZ operation.
- Q-LAN Video Transport: Sends video, power, and control data through the Q-SYS network for simplified system design.
- Power over Ethernet: Supports PoE Type 1, Class 3 operation for cleaner installation over a single network cable.
- Complete Imaging Control: Provides white balance, focus, exposure, shutter, and noise reduction controls for tuned room capture.
- HDMI and 3G-SDI Outputs: Connects to professional video workflows with local video output options.
- Image Rotation Support: Inverts video for upside-down installations, including optional ceiling-mounted applications.
- Included Wall Mount: Ships with the PTZ-WMB1 wall mount bracket for straightforward room installation.
Technical Specifications
- Product Type: Network PTZ conference camera
- Brand: Q-SYS
- Manufacturer: QSC Audio
- Product Line: Q-SYS
- Product Series: NC
- Model: NC-12x80
- Manufacturer Part Number: NC-12X80
- ADI Part Number: QB-NC12X80
- Image Sensor: 1/2.8" low-noise CMOS
- Lens: 12x optical zoom
- Focal Length: 3.47 to 41.65 mm
- Aperture: F1.84 to F3.72
- System Scanning Mode: Progressive
- Signal-to-Noise Ratio: Greater than or equal to 55 dB
- Horizontal Field of View: 80 degrees
- Horizontal Rotation Range: +/-170 degrees
- Vertical Rotation Range: -30 degrees to +90 degrees
- Pan Speed Range: 1.7 degrees/sec to 100 degrees/sec
- Tilt Speed Range: 1.7 degrees/sec to 69.9 degrees/sec
- Horizontal and Vertical Flip: Supported
- Minimum Illumination: 0.5 lux at F1.8, AGC on
- Shutter: 1/30 sec to 1/1000 sec
- White Balance: Auto, indoor, outdoor, one push, manual, specified color temperature
- Digital Noise Reduction: 3D digital noise reduction
- Supported Bridging Formats: MJPEG and YUY2 with compatible Q-SYS bridging hardware
- Supported Bridging Resolutions: 1080p at 30 or 15 fps; 720p at 30 or 15 fps; 360p at 30 or 15 fps; 180p at 30 or 15 fps
- IP Stream Resolutions: H.264 at 360p, 270p, or 180p for preview window
- HDMI Output: RGB 4:4:4 8-bit
- HDMI Video Formats: 2160p at 25, 29.97, or 30 fps; 1080p at 25, 29.97, 30, 50, 59.94, or 60 fps; 1080i at 50, 59.94, or 60 fps; 720p at 30, 50, 59.94, or 60 fps
- 3G-SDI Video Formats: 1080p at 25, 29.97, 30, 50, 59.94, or 60 fps; 1080i at 50, 59.94, or 60 fps; 720p at 50, 59.94, or 60 fps
- Network Interface: 1000BaseT Ethernet, IEEE 802.3ab
- Host Interface: USB 3.0
- Maximum Video Resolution: 1920 x 1080
- Maximum Frame Rate: 30 fps
- DC Power Input: 12 V +/-20%, 12 W, JEITA connector
- Power over Ethernet: PoE Type 1, Class 3
- Power Consumption: 12.95 W maximum
- Operating Temperature: 32°F to 104°F
- Storage Temperature: -40°F to 140°F
- Mount Type: Wall mount; optional ceiling mount supported
- Dimensions: 5.60" W x 6.70" D x 7.95" H
- Weight: 3.50 lbs
- UPC: 684284086549
What's Included
- Q-SYS NC-12x80 Network PTZ Conference Camera: Main network PTZ conference camera
- Wall Mount: Included wall mount bracket for installation
