Description
The Sonance PowerZone Connect 1008 (UBX-888-025) is a 1000-watt, 8-channel DSP-enabled Class-D matrix smart amplifier engineered for commercial and residential installed audio. Powered by Pascal UMAC Class-D technology, it delivers 8 x 125 W into 4 or 8 ohms, or 4 x 250 W into 70V/100V constant-voltage lines, with intelligent power sharing that automatically distributes the full 1000 W proportionally across low-impedance and high-impedance zones. Its compact 1U form factor makes it a space-efficient powerhouse for restaurants, retail, offices, fitness studios, and whole-home audio systems.
Setup and tuning are handled through the built-in PowerZone Control web app, accessible over the network or via the amplifier's built-in wireless access point β no software install required. Full-matrix DSP configuration lets integrators route any of the analog and digital inputs to any output zone, with per-channel EQ, crossover, limiting, and delay to dial in each space. S/PDIF digital input/output, balanced and unbalanced analog inputs, and configurable GPIO give the PowerZone Connect 1008 the flexibility to integrate with virtually any source or control system.
Because it drives both conventional 4β16 ohm loudspeakers and 70V/100V transformer-coupled distributed speaker lines from the same chassis, the UBX-888-025 replaces multiple dedicated amplifiers in mixed-topology installs β reducing rack space, cabling, and cost while maintaining audiophile-grade sound quality across every zone.
Features
- 8-channel Class-D smart amplifier with 1000 W total system power
- 8 x 125 W @ 4/8 ohms (Lo-Z) or 4 x 250 W @ 70V/100V (Hi-Z) with automatic power sharing
- Powered by Pascal UMAC Class-D amplifier technology
- Full-matrix DSP configuration via built-in PowerZone Control web app
- Built-in wireless access point for easy setup β no dedicated software required
- Balanced and unbalanced analog inputs plus S/PDIF digital input/output
- Configurable GPIO for integration with control systems
- Compact 1U rack form factor (rack kit sold separately)
- Drives low-impedance (4β16 ohm) and constant-voltage (70V/100V) speaker systems
Technical Specifications
- Model: PowerZone Connect 1008 (part number UBX-888-025)
- Channels: 8 (Lo-Z) or 4 (Hi-Z), mixable with power sharing
- Power output: 8 x 125 W @ 4/8 ohms; 4 x 250 W @ 70V/100V; 1000 W total
- Amplifier class: Class-D (Pascal UMAC)
- DSP: full-matrix routing, EQ, crossover, limiting via PowerZone Control web app
- Digital I/O: S/PDIF input and output
- Control: Ethernet (RJ45), built-in Wi-Fi access point, configurable GPIO
- Form factor: 1U rack height
- Dimensions: 17.3" W x 1.7" H x 12.6" D (439.4 x 43.2 x 320 mm)
- Weight: 8.4 lb (3.81 kg)
What's Included
- Sonance PowerZone Connect 1008 amplifier (UBX-888-025)
- Power cord
- Speaker/input connector plugs
- Quick start documentation
