SWIT CL-M100C 100W RGBW Mini Studio LED Panel with DMX

SWIT CL-M100C 100W RGBW Mini Studio LED Panel with DMX

The SWIT CL-M100C 100W RGBW mini studio LED panel is a compact, fanless color fixture for broadcast, film, theater, and live production. It delivers 3000 lux at 3.3 feet, spans 2800 to 10,000K, and combines RGB color control, gel presets, lighting effects, Bluetooth, and DMX512 operation.

Designed for low-ceiling studios and space-conscious installations, this professional RGBW LED panel creates white light, saturated colors, and precisely tuned effects from one fixture. CCT, HSI, RGB, CIE, GEL, and EFF modes support interviews, virtual production, theatrical sets, livestreaming, and creative background lighting. Built-in Rosco and LEE gel presets simplify repeatable color selection.

Time-Division Drive technology directs available power toward the active RGB LEDs for brighter saturated-color output. A 3.5-inch color LCD provides visual control, while the SWIT Console mobile app supports wireless operation from compatible iOS and Android devices. Five-pin DMX512 connections and PowerCON TRUE1 AC pass-through integrate the fixture into professional studio lighting systems.

Key Features

• 100W RGBW Output: Produces white light, saturated colors, and creative effects for professional studio applications.
• Extended CCT Range: Adjusts continuously from 2800 to 10,000K in precise 50K increments.
• Six Color Modes: Includes CCT, HSI, RGB, CIE, GEL, and EFF operating modes.
• Integrated Gel Library: Provides 20 Rosco and 20 LEE gel presets for repeatable color selection.
• Bluetooth App Control: Works with the SWIT Console app on compatible iOS and Android devices.
• Professional DMX512 Control: Five-pin input and output connections support centralized lighting operation.
• Fanless Cooling: Passive thermal management eliminates fan noise during audio-sensitive productions.
• AC Power Pass-Through: PowerCON TRUE1 input and output simplify multi-fixture studio installations.

Technical Specifications

• Model: CL-M100C
• Fixture Type: RGBW SMD LED light panel
• Panel Format: 1:1/2 mini studio panel
• LED Configuration: 170 RGB LEDs and 340 white LEDs
• Output Power: 100W
• Power Consumption: 100W
• Illuminance at 3.3 Feet: 3000 lux / 278 fc
• Illuminance at 6.6 Feet: 854 lux / 79 fc
• Illuminance at 9.8 Feet: 384 lux / 35 fc
• Color Temperature: 2800 to 10,000K
• Color-Temperature Adjustment: 50K increments
• Green/Magenta Adjustment: ±1.00 in 0.01 increments
• Color Modes: CCT, HSI, RGB, CIE, GEL, and EFF
• Gel Presets: 20 Rosco gels and 20 LEE gels
• CRI: 96
• TLCI: 93
• SSI: 73
• Dimming: 0 to 100% PWM digital dimming
• Dimming Adjustment: 0.1% increments
• Beam Angle: 62° half-peak
• Cooling System: Passive and fanless
• Preprogrammed Effects: Yes
• Onboard Display: 3.5-inch color LCD
• Control Methods: Onboard controls, DMX512, and Bluetooth mobile app
• Wireless Control: Bluetooth
• Mobile App: SWIT Console for compatible iOS and Android devices
• DMX Connections: Five-pin XLR input and output
• USB Connection: USB-A power output and firmware-update port
• Power Source: AC power
• AC Input: 100 to 240V AC, 50/60Hz
• AC Connections: PowerCON TRUE1 input and loop output
• Power Pass-Through: Yes
• Inline Power Switch: No
• Included Light Modifier: Built-in four-leaf metal barndoors
• Included Diffusion: Built-in
• Front Accessory Mount: Proprietary
• Optional Grid: LA-GM100 45° honeycomb
• Yoke Type: Manually operated yoke
• Fixture Mount: 1/2-inch receiver with 5/8-inch receiver through the yoke
• Lighting Area: 9.65" x 5.75"
• Fixture Dimensions: 10.83" x 6.89" x 5.12"
• Dimensions with Yoke and Pin: 14.74" x 11.70" x 5.10"
• Weight: 11.20 lbs
• Shipping Carton Dimensions: 17.72" x 7.87" x 14.57"
• Packaged Weight: 14.88 lbs
• Built-In Flash: No
• Umbrella Mount: No
• Storage Case Included: No
• Environmental Resistance: No

What's In the Box

• SWIT CL-M100C 100W RGBW Mini Studio LED Panel
• PowerCON TRUE1 AC power cable
• Two safety ropes
