SWIT KA-S21B B-Mount to V-Mount 28.8V Conversion Plate

SWIT KA-S21B B-Mount to V-Mount 28.8V Conversion Plate

The SWIT KA-S21B B-mount to V-mount conversion plate enables compatible V-mount cameras and production devices to operate from a high-voltage B-mount battery. It passes a 21.6–33.6V output through the V-mount connection, supporting professional equipment designed for nominal 28.8V power systems.

Built for cinema crews using mixed battery and camera ecosystems, the KA-S21B provides a practical way to connect SWIT HB-A290B and BIVO-series batteries to suitable V-mount devices. Its thin, lightweight design minimizes unnecessary bulk on the camera while preserving access to the higher-voltage capabilities of the attached battery.

The conversion plate is particularly suited to the RED V-Raptor XL, which requires 28.8V input to activate its onboard DC output connections. When paired with a compatible B-mount battery, the adapter powers the camera across the battery’s 21.6–33.6V operating range. Connected equipment must support input voltages up to 33.6V.

Key Features

• B-Mount Battery Conversion: Enables compatible V-mount cameras and devices to operate from a B-mount battery.
• High-Voltage Output: Passes a nominal 28.8V supply across a 21.6–33.6V operating range.
• RED V-Raptor XL Support: Provides the high-voltage input required to activate the camera’s onboard DC outputs.
• SWIT Battery Compatibility: Supports HB-A290B, BIVO-98, BIVO-160, BIVO-200, and BIVO-290 batteries.
• Direct Mounting: Combines a B-mount battery interface with a V-mount camera-side connection.
• Thin Construction: Adds minimal depth when adapting a B-mount battery to compatible equipment.
• Lightweight Design: Reduces unnecessary weight in professional camera power configurations.

Technical Specifications

• Model: KA-S21B
• Product Type: B-mount battery to V-mount conversion plate
• Battery-Side Mount: B-mount
• Device-Side Mount: V-mount
• Nominal Input Voltage: 28.8V
• Input Voltage Range: 21.6–33.6V
• Nominal Output Voltage: 28.8V
• Output Voltage Range: 21.6–33.6V
• Compatible SWIT Batteries: HB-A290B, BIVO-98, BIVO-160, BIVO-200, and BIVO-290
• Compatible Camera: RED V-Raptor XL
• Device Voltage Requirement: Connected V-mount equipment must support input up to 33.6V
