SWIT MINO-S140 140Wh 65W USB-C Pocket V-Mount Battery

SWIT MINO-S140 140Wh 65W USB-C Pocket V-Mount Battery

The SWIT MINO-S140 140Wh USB-C pocket V-Mount battery supplies compact, high-capacity power for cinema cameras, monitors, lights, laptops, and production accessories. Its 14.4V lithium-ion system supports a continuous 150W, 12A load while providing D-Tap, USB-A, and bidirectional USB-C connectivity for versatile professional rigs.

Designed for cinematographers, broadcast crews, drone operators, and mobile production teams, the MINO-S140 fits compact camera builds without sacrificing runtime. Buyers seeking a high-capacity pocket V-Mount battery, a 65W USB-C camera battery, or portable power for high-draw cinema equipment gain 140Wh capacity from a body sized for handheld rigs and RED V-RAPTOR installations.

A four-step LED gauge provides quick remaining-capacity checks, while compatible Sony and RED cameras can receive battery information through the V-Mount contacts. Wire-free internal construction connects cells and ports directly to the circuit board, reducing internal resistance. Multiple circuit protections, cold-weather discharge support, and 3.94-foot drop resistance prepare the battery for demanding location workflows.

Key Features

• 140Wh Pocket Capacity: Delivers 9.7Ah of professional power in an ultracompact V-Mount enclosure.
• 150W Continuous Load: Supports high-draw cinema cameras, production monitors, and LED lighting at up to 12A.
• 65W USB-C Output: Powers compatible laptops, tablets, cameras, and accessories through multiple voltage profiles.
• 48W USB-C Charging: Accepts bidirectional USB-C power and can recharge fully in approximately 3.5 hours.
• Multiple Power Connections: Includes V-Mount contacts, a D-Tap input/output, USB-A output, and USB-C input/output.
• Camera Power Communication: Passes remaining battery information to compatible Sony and RED camera displays.
• Wire-Free Internal Design: Directly connects cells and ports to the circuit board for stable, efficient power delivery.
• Production-Ready Protection: Features multiple circuit safeguards and resistance to drops from up to 3.94 feet.

Technical Specifications

• Model: MINO-S140
• Battery Type: Rechargeable lithium-ion camera battery
• Battery Mount: V-Mount
• Nominal Voltage: 14.4V DC
• Capacity: 140Wh, 9.7Ah / 9700mAh
• Cell Configuration: Eight high-capacity lithium-ion cells
• Continuous Load: 150W, 12A
• V-Mount Contact Output: 150W, 12A
• V-Mount Contact Charging Input: 16.8V DC, 3A
• D-Tap Connection: One female input/output port
• D-Tap Output: 120W, 10A
• D-Tap Charging Input: 16.8V DC, 3A, 50W maximum
• USB-A Output: 5V DC, 2A, 10W
• USB-C Connection: One female input/output port
• USB-C Output: 5V, 9V, 12V, 15V, or 20V DC at up to 3.25A
• Maximum USB-C Output: 65W
• USB-C Charging Input: 5V, 9V, 12V, 15V, or 20V DC at up to 2.4A
• Maximum USB-C Charging Input: 48W
• USB-C Charging Time: Approximately 3.5 hours with a compatible charger
• Supported USB Protocols: BC1.2, PD 2.0, PD 3.0, QC 2.0, QC 3.0, FCP, and SCP
• Battery Indicator: Four-step LED capacity gauge
• Camera Information Support: Compatible Sony and RED battery data pass-through
• Internal Construction: Wire-free circuit-board design
• Drop Resistance: Up to 3.94 feet
• Accessory Mounting Thread: None
• Charging Temperature: 32 to 104°F
• Discharging Temperature: -4 to 122°F
• Low-Temperature Performance: Capacity and maximum load may decrease below 32°F
• Dimensions: 4.1" x 3.1" x 2.2"
• Weight: 1.6 lbs
• Package Weight: 1.66 lbs
• Box Dimensions: 4.5" x 3.2" x 2.4"

What's In the Box

• SWIT MINO-S140 140Wh Pocket V-Mount Battery
