SWIT S-2041U 23W COB LED On-Camera Light with Sony BP-U Plate

SWIT S-2041U 23W COB LED On-Camera Light

The SWIT S-2041U COB LED On-Camera Light delivers soft, evenly distributed illumination for interviews, field production, and location video. Its 23W chip-on-board LED produces output comparable to a 100W halogen fixture while maintaining a compact design, wide 60° beam, low heat, and convenient camera-mounted operation.

This portable camera light suits videographers who need dependable close-range lighting without harsh glare or multiple shadows. A built-in dimmer adjusts output from 10% to 100%, while hinged 3200K and 5600K filters quickly adapt the native 5000K output for tungsten or daylight environments. It is an efficient choice for interviews, documentary production, event coverage, and mobile ENG workflows.

The included S-7004U interchangeable battery plate supports Sony BP-U batteries and compatible SWIT battery packs. A 6 to 17 VDC input also allows operation from professional battery systems through the included D-Tap power cable. The adjustable mounting base connects through a camera accessory shoe or 1/4"-20 thread, providing flexible positioning on cameras, cages, and support equipment.

Key Features

• Chip-on-Board LED: Produces soft, evenly spread light with reduced glare and a clean single shadow.
• Efficient 23W Output: Delivers illumination comparable to a traditional 100W halogen fixture.
• Adjustable Color Temperature: Uses hinged filters to switch between 3200K, 5000K, and 5600K lighting.
• 10–100% Dimming: Provides smooth brightness control through an accessible front-mounted dial.
• Wide 60° Beam: Covers subjects evenly without a pronounced beam edge or concentrated hotspot.
• Sony BP-U Battery Plate: Includes the interchangeable S-7004U plate for compatible Sony and SWIT batteries.
• Flexible DC Power: Accepts 6 to 17 VDC input and includes a D-Tap power cable.
• Dual Mounting Options: Attaches through an accessory shoe or 1/4"-20 threaded mounting point.

Technical Specifications

• Model: S-2041U
• Fixture Type: On-camera COB LED light
• LED Technology: Chip-on-board LED
• Power Consumption: 23W maximum
• Halogen-Equivalent Output: 100W
• Illuminance: 1800 lux at 3.3 feet
• Beam Angle: 60° horizontal and vertical
• Native Color Temperature: 5000K
• Filter Color Temperatures: 3200K and 5600K
• Color Rendering Index: CRI 85
• Dimming Range: 10% to 100%
• Cooling System: Passive cooling
• Input Voltage: 6 to 17 VDC
• Power Sources: DV battery plate or D-Tap power connection
• Included Battery Plate: SWIT S-7004U Sony BP-U plate
• Compatible Sony Batteries: BP-U60 and BP-U30
• Compatible SWIT Batteries: S-8U93 and S-8U63
• Battery Included: No
• Power Input: Barrel-style DC input
• Included Power Cable: 2-foot D-Tap to barrel power cable
• Fixture Mounting: Accessory shoe and 1/4"-20 female thread through swivel mount
• Dimensions: 6.2" x 4.1" x 3.3"
• Weight: 0.88 lbs
• Package Dimensions: 9.9" x 6.4" x 4.7"
• Package Weight: 2.25 lbs

What's In the Box

• SWIT S-2041U COB LED On-Camera Light
• SWIT S-7004U Sony BP-U Battery Plate
• SWIT S-7104 D-Tap to Barrel Power Cable
• Spare Cold-Shoe Connector
• Portable Carrying Pouch
