TOA Electronics B-01F Female XLR Balanced Line Input
The B-01F is a line input module to be used in conjunction with the 900 series components and other TOA's equipment. It has a transformer balanced line input with female XLR type connector.
Technical Specifications
Input Sensitivity
-18 dB* (Rated output: -20 dB*)
Input Impedance
10 k, balanced transformer-isolated
Frequency Response
20 Hz - 20 kHz %%p1.5 dB
Connector
Female XLR connector (XLR-3-31 equivalent)
Dimensions
35 (W) - 78 (H) - 88 (D) mm (1.38 - 3.07" - 3.46")"
Weight
Max. 110 g (0.24 lb)
