TOA Electronics P-924MK2 UL 240 Watt Single Channel Power Amplifier

The P-924MK2 Power Amplifier delivers up to 240 watts (Direct)/220 watts (Transformer) of output power. The power amplifier has an input port to accept one plug-in module.

Technical Specifications

Type
Power amplifier
Power Requirement
AC mains, 120 V, 60 Hz
Power Consumption
120 V /3 A
Output Power
(D) 240 W RMS
(T) 220 W RMS
Power Band Width
(D) 20 20,000 Hz, 0.5 % THD
(T) 50 20,000 Hz, 0.5 % THD
Frequency Response
(D) 20 20,000 Hz, -1 dB
(T) 20 15,000 Hz, -1 dB, (T) 20 20,000 Hz, +1 dB, -3 dB
T.H.D
0.01 % at 1 kHz, rated output
Inputs
One Input Port: Port accepts any input module exept T-01.
Input Sensitivity /Impedance
Input Port: 100 mV or 1000 mV (switchable)/10 k
Direct Input: 100 mV or 1000 mV (switchable)/10 k
Outputs(T)=Transformer (D)=Direct
Main (T): 8 , 25 and 70 volts, balanced
Main (D): 4 , unbalanced
Output Regulation(1kHz)
(D) Less than 0.5 dB, no load to full load
(T) Less than 1.0 dB, no load to full load
S/N Ratio(Band Pass 20-20,000Hz)
Input level switch in 0 dBV (1000 mV) position: 108 dB
Input level switch in -20 dBV (100 mV) position: 90 dB
Controls
1 Input gain control 1 Input level switch
1 Power ON/OFF switch 1 Low-Cut switch
Indicators
1 Power LED, 1 Protect LED, 1 Signal LED, 1 Normal LED, 1 Peak LED
Protection
Self-protection, with 2AC fuses and 2DC fuses (inside)
Connectors
Input: Card-edge connector and screw-terminal strip
Output: Screw-terminal strip
AC outlet: 3-pin grounding type
AC power cord/plug: SJT, 3-prong type
Finish
Black
Dimensions
420 (W) 151.3 (H) - 334.2 (D) mm
Weight
19.5 kg
